    DVI-FEMALE TO VGA-MALE CABLE Question

    Discussion in 'Accessories' started by Divert, Dec 25, 2008.

  1. Divert

    Divert Notebook Geek

    Reputations:
    0
    Messages:
    87
    Likes Received:
    0
    Trophy Points:
    15
    I have a Dell Inspiron 1520 that only have a VGA port on the machine itself and I would like to hook it up to a monitor (Dell UltraSharp 2208WFP) using DVI. Would any DVI-FEMALE to VGA-MALE converter work or would I need a specific one to do this?

    Divert, Dec 25, 2008
    #1
  2. paper_wastage

    paper_wastage Beat this 7x7x7 Cube

    Reputations:
    486
    Messages:
    2,596
    Likes Received:
    24
    Trophy Points:
    56
    paper_wastage, Dec 25, 2008
    #2
  3. PhoenixFx

    PhoenixFx Notebook Virtuoso

    Reputations:
    744
    Messages:
    3,083
    Likes Received:
    0
    Trophy Points:
    105
    You cannot use a cable converter; because 2208WFP has a DVI-D input, which means you can ONLY input a digital signal through that. your only option is VGA (analog).

    Otherwise you'll have to but an external docking station with a DVI output or use somesort of an external signal converter to convert the analog video signal to a digital signal, but converting the signal through an external signal converter is almost pointless and expensive, because your monitor is anyway doing that inside for analog signals anyways.

    PhoenixFx, Dec 25, 2008
    #3
