Upgraded GPU to 580m Boot Up Graphic Issued

I upgraded my m17x r3 gpu to 580m, when it boot up the picture show as below, have anyone have this problem before. please help to fix this

thanks



The matrix has taken root in your computer...



I'm really bad with hardware but those are definitely screen artifacts. I don't know if they're RAM artifacts or BUS artifacts but the most common cause other than a faulty card is overheating and overclocking.

Where did you get the 580M and did you install it yourself?
If so, have you tried reseating the card?
Do you have the correct heatsink for the 580M?
Did you properly apply thermal paste and properly position all the thermal pads?
Is your GPU fan spinning?

Have you overclocked the card at all?



That just means your backplate is not properly insulated



did yo disable the internal GPU (HD3000) in bios ? If not, then these artefacts is coming from HD3000, or ?



Thanks guys for reply

Internal GPU was disable

I bought it from Ebay and installed it myself, I did applied new thermal paste and reseated the card 3-4 times and I used the old heatsink from 560m, I dont think the card is overlocked and I still have same issue before.



To restate Widezu69's query, does your 580M include the large thermal pad on the back of the card that serves to dissipate heat from one bank of VRAM and to insulate the card from the motherboard?



I looked at the thermal pad of backplate and it doesn't cover the whole size of the 580m gpu die, and I compared the 560m die is much smaller than 580m, that maybe why the heatsink doesn't work for 580m.



Someone correct me if I'm wrong but I think you're talking about something different. I believe that you're referring to the copper portion of the heatsink that contacts the GPU die while Widezu and Rev are talking about the thermal pad on the backside of the card itself, pictured here:



In the case of the copper portion of the heatsink not covering the die, I believe there is black tape that can be removed to expose more copper. Again, someone please verify.



That's a different issue, but also important. Short term, you need to remove all of the black thermal facing/material on the bottom of the heatsink so that the entire bottom is solid copper to facilitate direct copper to die contact for the entire 580M die. My 580M came with a 460M heatsink, so I had the same problem. However, that is a cooling issue and not the cause of the artifacts you are seeing. Longer term, you need to buy the new and improved 580M heatsink (comes with backplate and thermal pads) which will give you noticeably improved cooling and only costs $25.00. Part Number is V1K2G -- Thermal Heatsink Assembly.

But one possible culprit in the artifacts problem is electrical interference caused by contact between the exposed circuits on the back of the 580M and the motherboard. A large thermal pad should be attached to the back as shown below; if you have one that looks and is positioned substantially like that one, then it's a false trail, and the problem lies elsewhere. If that pad is not there, that is very likely the problem.

​

Edit: @aznpos531 -- didn't see your post until after I had posted. We're on the same wavelength, but you have the better picture.



Heh, I wasn't sure if I was totally accurate so it's good that you posted to confirm



thank you for your time to reply, so what I did is removed all the black material so the entire solid copper faced directly m580 die, re-applied thermal paste. I looked at the back of 580m , it had a large pad thermal attached on the back exactly like the one you had in the picture, put all back together, fired it up and the pictures was same as before nothing change.



I've had this issue before. I just added more sticker to the side of the backplate which makes contact with the GPU, the sticky bit. Solved it. You should try it with a bit of insulating tape.



can you post the pictures of the backplate? I gonna try to copy yours to solve my issue
thanks
