nVidia GO 6600 Info

​

Official NVIDIA GO 6600 Website
http://www.nvidia.com/page/go_6600.html

Memory Interface 128-bit
Memory Bandwidth (GBps) 11.2 GBps
Fill Rate (pixels/sec.) 3 billion
Vertices/Second 300 million
RAMDACs 400 MHz



********************************************
nVidia GO 6600 GPU Performance Test
********************************************
*Note:
* All test based upon Asus Z71V nVidia GO 6600
* Asus Z71V STOCK SETTING IS: 250/500
* Toshiba used GO 6600 TC, which is slower
than one used in Asus Z71V

nVidia Driver v71.13
* Asus Stocked Video Driver
3D Mark 2005: 1720 (250/500 Stocked Setting)
3dMark 2005 2018 (275/563)

nVidia 80.40 Beta Leaked
* AA OFF, Resolution 1024x768
3DMark05: 1821 (250/500 stocked setting)
3DMark05: 2121 (290/575 OC Setting)
3DMark05: 2236 (300/600 OC Setting)

* AA 2x, Resolution 1024x768
3DMark05: 1813 (250/500 stocked setting)
3DMark05: 1975 (290/575 OC Setting)
3DMark05: 2072 (300/600 OC Setting)

* AA 4x, Resolution 1024x768
3DMark05: 1523 (250/500 stocked setting)
3DMark05: 1733 (290/575 OC Setting)
3DMark05: 1817 (300/600 OC Setting)


*********************************************
OLDER VERSION OF NVIDIA DRIVERS
*********************************************
Using XtremeG nVidia Driver v71.84
3D Mark 2005: 1780 (Stocked Setting)
3D Mark 2005: 1970 (300 Core / 500 Memory)

By CMYK (his Asus Z71v - Driver: v76.44)
3DMark05: 1787 (Stocked Setting)

nVidia 77.30
3DMark05: 1813 (stocked setting)
3DMark05: 2060 (300 Core / 500 Memory)

nvidia 77.50
3DMark05: 1820 (stocked setting)
3DMark05: 2060 (300/500 OC Setting)

nVidia 77.62
3DMark05: 1820 (stocked setting)
3DMark05: 2055 (300/500 OC Setting)
3DMark05: 2120 (290/575 OC Setting)

Using XG 77.62-HD Type 2 nVidia Driver v77.62
3DMark05: 1820 (Stocked Setting)
3DMark05: 2074 (300/500 OC Setting)
3DMark05: 2169 (290/575 OC Setting)
3DMark05: 2215 (300/600 OC Setting)

nVidia 77.72 Official WHQL Release
3DMark05: 1820 (stocked setting)
3DMark05: 2069 (300/500 OC Setting)
3DMark05: 2223 (300/600 OC Setting)

*********************************************
WHERE TO GET NVIDIA DRIVERS
*********************************************
* forums.guru3d.com
* www.laptopvideo2go.com/forums/
* www.nvidia.com
*
*********************************************
How To Install
*********************************************
1) Download the nvidia driver
2) Extract it to a directory

-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-
3a) download the latest INF file from http://www.laptopvideo2go.com/forum/ and save it
to the same directory you had extracted earlier.

-OR-

3b) Use the NVAM.INF file that came with the original Asus Z71V display driver. You could download
it from http://support.asus.com and extract out the NVAM.INF from there.
-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-

4) Right click on the desktop and go to properties. This will take you
to the display control panel.
5) Click on the settings tab
6) Click on Advanced button
7) Click on Adapter tab
8) Click on Properties button
9) Click on Driver tab
10) Click on Update Driver button
11) Click on "No, Not this time" when asked "Can Windows Connect To Windows Update..."
12) Click on "Install from a list or specific location"
13) Click on "Don't Search, I will choose the driver to install"
14) Click on "Have Disk"
15) Browse to the location where you had saved the INF file earlier
16) Select the video card from the list, in Asus Z71V case it is nVidia GeForce Go 6600
17) Continue with install...

*USE AT YOUR OWN RISK!*



Awesome submission! Thanks for compiling all this information! I'll definitly be checking this out again when I get my Z71v (hopefully next week)



whats lowlymarine talking about the x700 is faster than the go6600 on 3dmark05 at stock settings and stock drivers, (at least on my laptop) his gpu chart is missleading



From what'ive seen so far, the X700 is faster than go6600. This is comparing the Acer 8100 series x700 against

Asus Z71V w/nvidia go6600
Sager 3380 w/nvidia go6600
Toshiba Tecra Series w/nvidia go 6600

Of the 3, the Toshiba score the lowest, Sager score the highest. Asus is right in the middle.

I believe the sager uses a different memory and core on it, as nvidia did release 3 version of the 6600 core. It was able to be over clocked much more than Asus. I am not sure because of the heatsink is better or not. Still trying to figure out
