    Connecting 4k XPS 9550 and DELL P2715Q

    Discussion in 'Dell XPS and Studio XPS' started by Laki021, Feb 21, 2016.

  1. Laki021

    Laki021 Notebook Enthusiast

    Reputations:
    0
    Messages:
    41
    Likes Received:
    6
    Trophy Points:
    16
    Does anyone know how properly to connect XPS 9550 and Dell P2715Q 4k @60Hz.

    So far using all possible combinations I managed to connect them just at 30Hz, and this is simply irritating and it hearts my eyes and brain :)

    XPS 15 does not have Displayport output, while its HDMI output is 1.4 (limited to @30Hz). Then I bought Dell USB-C to HDMI 2 adapter just to discover that P2715Q also has just HDMI 1.4 input, and for 60Hz I need Displayport connection... so once again I manged to connect them @30Hz. Additionally this adapter causes many other problems (it is simply not tested product, problems with drivers, firmware, vertical lines on the screen...), so I returned it.

    The problem is I cannot find any adapter USB-C Thunderbolt 3 to Displayport.

    Is it possible that at the moment there is no way to properly connect Dell's best laptop withe their best screen? I am trying to do this for about a month now, I bought all sorts of cables and adapters, but nothing works :)

  2. david.keller

    david.keller Notebook Enthusiast

    Reputations:
    0
    Messages:
    10
    Likes Received:
    1
    Trophy Points:
    6
    You don't need USB-C Thunderbolt 3, just get USB-C to DisplayPort adapter.

  3. Laki021

    Laki021 Notebook Enthusiast

    Reputations:
    0
    Messages:
    41
    Likes Received:
    6
    Trophy Points:
    16
    Thanks.
    I was searching for this, but unfortunately, seems that such adapter is not yet available in Switzerland (I just checked again), but this time it is at least available for preorder.
    I will order it from abroad. Its seems that it is not so easy to get this kind of cable/adapters at the moment.

    I found on the internet several people with same problem, and they all had to go with 30Hz at the end, so I thought this kind of adapter does not exist...

  4. david.keller

    david.keller Notebook Enthusiast

    Reputations:
    0
    Messages:
    10
    Likes Received:
    1
    Trophy Points:
    6
  5. Laki021

    Laki021 Notebook Enthusiast

    Reputations:
    0
    Messages:
    41
    Likes Received:
    6
    Trophy Points:
    16
  6. kent1146

    kent1146 Notebook Prophet

    Reputations:
    2,354
    Messages:
    4,449
    Likes Received:
    476
    Trophy Points:
    151
    Be careful with the adapters you buy. Most of the thunderbolt (USB type c) to display port adapters are only 4K 30Hz.

    Some company just released one that does 4K 60Hz. Be sure to look for that.

    Sent from my XT1575 using Tapatalk

  7. Laki021

    Laki021 Notebook Enthusiast

    Reputations:
    0
    Messages:
    41
    Likes Received:
    6
    Trophy Points:
    16
    That is true.

    This one that I linked and ordered now is 4k @60Hz, I think I can trust Google store :)

  8. AM Radio

    AM Radio Notebook Evangelist

    Reputations:
    21
    Messages:
    308
    Likes Received:
    11
    Trophy Points:
    31
  9. LOUSYGREATWALLGM

    LOUSYGREATWALLGM Notebook Deity

    Reputations:
    172
    Messages:
    1,053
    Likes Received:
    10
    Trophy Points:
    56
    What about the Monoprice usb-c to dp adapater, description says it support 4K @60Hz? Anyone tried this?

  10. AM Radio

    AM Radio Notebook Evangelist

    Reputations:
    21
    Messages:
    308
    Likes Received:
    11
    Trophy Points:
    31
  11. AM Radio

    AM Radio Notebook Evangelist

    Reputations:
    21
    Messages:
    308
    Likes Received:
    11
    Trophy Points:
    31
  12. Laki021

    Laki021 Notebook Enthusiast

    Reputations:
    0
    Messages:
    41
    Likes Received:
    6
    Trophy Points:
    16
    Finally!
    After two month I managed to properly connect my XPS 15 and the screen!
    As mentioned, I am using this cable:
    https://store.google.com/product/usb_type_c_to_displayport_cable

    The connection was not so simple, first there was no image on the monitor, although computer could see the monitor. Then I changed resolution to 1080, and I finally got the picture. Then I was able to access monitors menu and set MST to OFF. After that it started working 4k@60Hz, although first computer crashed with BSOD, then scaling was wrong, but after few restarts now finally everything works fine, and it is really great to have so nice image and proper refresh rate!

  13. LOUSYGREATWALLGM

    LOUSYGREATWALLGM Notebook Deity

    Reputations:
    172
    Messages:
    1,053
    Likes Received:
    10
    Trophy Points:
    56
    @AM Radio How's the adapter performing? Is it issue free?

  14. AM Radio

    AM Radio Notebook Evangelist

    Reputations:
    21
    Messages:
    308
    Likes Received:
    11
    Trophy Points:
    31
  15. LOUSYGREATWALLGM

    LOUSYGREATWALLGM Notebook Deity

    Reputations:
    172
    Messages:
    1,053
    Likes Received:
    10
    Trophy Points:
    56
    @AM Radio Thanks for the heads up. Sadly couldn't find one other than the one you linked to.
