    Some tips to overclock my GTX560M

    Discussion in 'Gaming (Software and Graphics Cards)' started by NpTr, Jan 19, 2012.

  1. NpTr

    NpTr Notebook Guru

    Reputations:
    0
    Messages:
    59
    Likes Received:
    0
    Trophy Points:
    15
    Hello,
    I have a Asus G74SX and i wanna try to overclock my GTX560M.
    The maximum i could get was 930/1880/1550 (i believe that i can get more on the memory clock, but not on the core), i could run the 3dmark with this, without problems, and good temps, but when i tried to play BF3 the game crashed when playing for like 5/10, i tried some times and it only crashed when i had the oc on.
    Can I get better results? Unlocking the gpu voltage would help me? How can i do this?

    NpTr, Jan 19, 2012
    #1
  2. James5

    James5 Notebook Consultant

    Reputations:
    79
    Messages:
    193
    Likes Received:
    0
    Trophy Points:
    30
    Svet's vbios tool is what you want on most cards it allows adjustment of voltages

    James5, Jan 19, 2012
    #2
  3. SlickDude80

    SlickDude80 Notebook Prophet

    Reputations:
    3,262
    Messages:
    4,997
    Likes Received:
    3
    Trophy Points:
    106
    That's a good overclock for a 560m, i dont' think you're gonna get much better on stock voltage

    SlickDude80, Jan 19, 2012
    #3
  4. imglidinhere

    imglidinhere Notebook Deity

    Reputations:
    387
    Messages:
    1,077
    Likes Received:
    59
    Trophy Points:
    66
    The GTX 460M and 560M cannot be pushed further for voltage. I've tried on mine and seen that both are locked. No voltage can be added. :(

    But I say back off on the core to around 900mhz and push the memory as high as you can get. Run Vantage three times and if it's stable on the third time around with a similar score to the first, off by only a few points, and your temps are reaching normal gaming levels, you're stable.

    Post the score too. I hit 750/1500/3200 on my 460M and match a 470M now. :D

    imglidinhere, Jan 19, 2012
    #4
  5. NpTr

    NpTr Notebook Guru

    Reputations:
    0
    Messages:
    59
    Likes Received:
    0
    Trophy Points:
    15
    Thanks, i will try it, just one more question.
    I'm using msi afterburner to overclock, and the maximum memory i can set is 1625, is there any way to unlock or maybe another software?

    NpTr, Jan 19, 2012
    #5
  6. VAL@NBR

    VAL@NBR Notebook Consultant

    Reputations:
    51
    Messages:
    128
    Likes Received:
    0
    Trophy Points:
    30
    Add a second one... :D

    [​IMG]

    VAL@NBR, Jan 19, 2012
    #6
