    Core 2 quad q9100 looks odd?

    Discussion in 'Hardware Components and Aftermarket Upgrades' started by Tippey764, Nov 3, 2008.

  1. Tippey764

    Tippey764 Notebook Deity

    Reputations:
    377
    Messages:
    1,423
    Likes Received:
    0
    Trophy Points:
    55
    Tippey764, Nov 3, 2008
    #1
  2. Hep!

    Hep! sees beauty in everything

    Reputations:
    1,806
    Messages:
    5,921
    Likes Received:
    1
    Trophy Points:
    206
    Yeah, that's two dual core dies on one chip.

    Hep!, Nov 3, 2008
    #2
  3. Tippey764

    Tippey764 Notebook Deity

    Reputations:
    377
    Messages:
    1,423
    Likes Received:
    0
    Trophy Points:
    55
    Crazy it looks mutated lol

    Tippey764, Nov 3, 2008
    #3
  4. emike09

    emike09 Overclocking Champion

    Reputations:
    652
    Messages:
    1,840
    Likes Received:
    0
    Trophy Points:
    55
    Wow I've never seen it like that. Normally, the 4 dies are completely side by side. I have not seen them separated like that.

    emike09, Nov 3, 2008
    #4
  5. Hep!

    Hep! sees beauty in everything

    Reputations:
    1,806
    Messages:
    5,921
    Likes Received:
    1
    Trophy Points:
    206
    Could be a fake, ask for some better pictures.

    Hep!, Nov 3, 2008
    #5
  6. Andy

    Andy Notebook Prophet

    Reputations:
    2,133
    Messages:
    6,399
    Likes Received:
    1
    Trophy Points:
    206
    Andy, Nov 3, 2008
    #6
  7. BMW135i

    BMW135i Notebook Consultant

    Reputations:
    22
    Messages:
    291
    Likes Received:
    0
    Trophy Points:
    30
    The new i7 has all 4 on 1 die!

    BMW135i, Nov 3, 2008
    #7
  8. sonac

    sonac Notebook Enthusiast

    Reputations:
    0
    Messages:
    25
    Likes Received:
    0
    Trophy Points:
    5
    erase, please

    sonac, Apr 8, 2009
    #8
  9. stevezachtech

    stevezachtech Notebook Evangelist

    Reputations:
    14
    Messages:
    348
    Likes Received:
    0
    Trophy Points:
    30
    This processor model sure has a very strange architectural design, it looks as if it came from outer space..

    stevezachtech, Apr 16, 2009
    #9
  10. RainMotorsports

    RainMotorsports Formerly ClutchX2

    Reputations:
    565
    Messages:
    2,382
    Likes Received:
    2
    Trophy Points:
    56
    LOL and @BMW, probably why the cheap i7 920 performs better then some of the high end Q series. Having them connected proper like the 2 cores in a dual core are rather then the way the Q is built would have a performance increase in communication.

    and yeah i totally explained that wrong lol.

    RainMotorsports, Apr 16, 2009
    #10
  11. TehSuigi

    TehSuigi Notebook Virtuoso

    Reputations:
    931
    Messages:
    3,882
    Likes Received:
    2
    Trophy Points:
    105
    ...the difference between the i7 920 and the Q9xxx Core 2 Duos is probably because they're on entirely different architectures.
    Moving the memory controller on-die probably helps.

    TehSuigi, Apr 16, 2009
