    Does the Western Digital Green GP has head ramp park?

    Discussion in 'Hardware Components and Aftermarket Upgrades' started by wobble987, Mar 3, 2009.

  1. wobble987

    wobble987 Notebook Virtuoso

    Reputations:
    543
    Messages:
    2,871
    Likes Received:
    0
    Trophy Points:
    55
    does the WD caviar Green GP 1TB on mybook studio, has head ramp park?

    wobble987, Mar 3, 2009
    #1
  2. K-TRON

    K-TRON Hi, I'm Jimmy Diesel ^_^

    Reputations:
    4,412
    Messages:
    8,077
    Likes Received:
    2
    Trophy Points:
    205
    All current harddrives have an area for the heads to park on the disc. This is usually in the center of the platter. The area is their, so that the harddrive can stay active when idling. The head simply flies above a region of the drive which has no data sectors below it.
    On old harddrives, when the drive powers down the heads go to the middle of the drive, closest to the motor. This is also the idling region of the drive. This made sense because the inner part of the drive was the slowest, so using it as a idle section was the best use for it.

    On new drives, when the drive powers off the heads fly off the disc and are held by a plastic protector. I am not sure what the manufacturer calls it, but it looks like this: (Its in the lower right corner - its the white piece of plastic)
    [​IMG]

    K-TRON

    K-TRON, Mar 3, 2009
    #2
