    How to remove HD?

    Discussion in 'Hardware Components and Aftermarket Upgrades' started by rbp, Dec 16, 2009.

  1. rbp

    rbp Notebook Enthusiast

    Reputations:
    0
    Messages:
    27
    Likes Received:
    1
    Trophy Points:
    5
    #1 is the OS, I think, and i dont see any way to slide it out or remove it, it is pretty firmly attached. There are 2 prongs on one end but not sure if those are what is holding it in place. there are 4 screws on the sides but they are below the level of the plastic and I would need to remove the bottom cover to access them. If i need to do that, is there a trick? This is a dv9420us.
    [​IMG] [​IMG]

    rbp, Dec 16, 2009
    #1
  2. Mr.KL

    Mr.KL Notebook Evangelist

    Reputations:
    27
    Messages:
    306
    Likes Received:
    0
    Trophy Points:
    0
    Get the manual before you break something!

    Mr.KL, Dec 16, 2009
    #2
  3. elijahRW

    elijahRW Notebook Deity

    Reputations:
    940
    Messages:
    1,797
    Likes Received:
    0
    Trophy Points:
    0
    elijahRW, Dec 16, 2009
    #3
  4. rbp

    rbp Notebook Enthusiast

    Reputations:
    0
    Messages:
    27
    Likes Received:
    1
    Trophy Points:
    5
    Got it! The manual said to lift up where the 2 screws holding the cover were and voila!

    Shaka bra. You stay know da good kine ting.

    rbp, Dec 16, 2009
    #4
  5. elijahRW

    elijahRW Notebook Deity

    Reputations:
    940
    Messages:
    1,797
    Likes Received:
    0
    Trophy Points:
    0
    GREAT!!!! :) :) :) :)

    elijahRW, Dec 16, 2009
    #5
  6. Mr.KL

    Mr.KL Notebook Evangelist

    Reputations:
    27
    Messages:
    306
    Likes Received:
    0
    Trophy Points:
    0
    Did you buy your new drive at the ABC Store? lol.

    Mr.KL, Dec 16, 2009
    #6
  7. deeastman

    deeastman Notebook Deity

    Reputations:
    977
    Messages:
    1,095
    Likes Received:
    0
    Trophy Points:
    55
    Yes, as you figured out just hold onto the semi-transparent plastic tab and what I do is use a small flat blade screw driver and gently insert under the tabs where the screw holes are and gently work the screw driver back and forth until the drive is loose. Usually the first time it is removed the drive fits extremely tight and is difficult to remove. Subsequent removals are easier.

    Remember that the drive, when removed, has a plastic piece (adapter) that fits over the pins on the end. You will need to take that piece off and put in on your new drive before you install it.

    Lots of people, the first time they replace the drive, ask why the new drive has a different configuration for the pins. It doesn't, but they don't realize there is an adapter attached to the old drive and has to be transfered to the new drive,

    deeastman, Dec 16, 2009
