    Quad core QX9300 in T400?

    Discussion in 'Lenovo' started by justmonkey 23, Oct 21, 2008.

  1. justmonkey 23

    justmonkey 23 Notebook Enthusiast

    Reputations:
    0
    Messages:
    23
    Likes Received:
    0
    Trophy Points:
    5
    Anyone know if the T400's processor can be removed or is it soldered to the motherboard? If it can be removed I would like to upgrade to quad core when newegg gets some in stock.

    justmonkey 23, Oct 21, 2008
    #1
  2. f4ding

    f4ding Laptop Owner

    Reputations:
    261
    Messages:
    2,085
    Likes Received:
    0
    Trophy Points:
    55
    You might burn your mobo if you do that.

    f4ding, Oct 21, 2008
    #2
  3. Charr

    Charr Notebook Deity

    Reputations:
    415
    Messages:
    1,564
    Likes Received:
    0
    Trophy Points:
    55
    You can change CPUs, but do not put in a quad core. The cooling system isn't near close enough to handle the extra heat. Only 17" laptops really have what it takes.

    Charr, Oct 21, 2008
    #3
  4. justmonkey 23

    justmonkey 23 Notebook Enthusiast

    Reputations:
    0
    Messages:
    23
    Likes Received:
    0
    Trophy Points:
    5
    If Intel releases a 35W quad core processor in the future?

    justmonkey 23, Oct 21, 2008
    #4
  5. jonlumpkin

    jonlumpkin NBR Transmogrifier

    Reputations:
    826
    Messages:
    3,240
    Likes Received:
    0
    Trophy Points:
    105
    I still wouldn't recommend it. The BIOS is unlikely to support it, and cooling/power consumption would probably be a nightmare.

    jonlumpkin, Oct 21, 2008
    #5
  6. ZaZ

    ZaZ Super Model Super Moderator

    Reputations:
    4,982
    Messages:
    34,001
    Likes Received:
    1,415
    Trophy Points:
    581
    Who knows. You probably just have to wait it out like the rest of us.

    ZaZ, Oct 22, 2008
    #6
  7. kickace

    kickace Notebook Deity

    Reputations:
    71
    Messages:
    1,054
    Likes Received:
    8
    Trophy Points:
    56
    they will have a 25w tdp quad core in the future....but then again, it all depends on how long u mean for the future :)

    i would say a 99% chance that a quad core cpu that fits in the t400 will not be made with a 35w tdp or lower....when that time comes, it will be a much newer chipset, different socket perhaps, etc

    kickace, Oct 22, 2008
    #7
  8. Andy

    Andy Notebook Prophet

    Reputations:
    2,133
    Messages:
    6,399
    Likes Received:
    1
    Trophy Points:
    206
    The QCs are not supposed to work in the standard C2D motherboards, mainly because the QCs have a different electrical pin-out, and may require a different socket P '.
    TDP really doesn't make a huge difference, if you can undervolt the cpu, and downclock it when on battery.

    And the mobile QCs have two dies smacked onto a single chip, and will need a heatsink with a larger surface area to cover both the dies. So, if the T400 doesn't release a QC version of the T400, you'll never find a larger heatsink to cover the QC....

    [​IMG]

    Last edited by a moderator: Feb 6, 2015
    Andy, Oct 22, 2008
    #8
  9. f4ding

    f4ding Laptop Owner

    Reputations:
    261
    Messages:
    2,085
    Likes Received:
    0
    Trophy Points:
    55
    They have quad-core in 15.4" (Dell, HP, Lenovo), but I think those must've been mod with some specialized cooling and power supplies.

    f4ding, Oct 23, 2008
    #9
  10. justmonkey 23

    justmonkey 23 Notebook Enthusiast

    Reputations:
    0
    Messages:
    23
    Likes Received:
    0
    Trophy Points:
    5
    Which lenovo laptops have a mobile quad core?

    justmonkey 23, Oct 23, 2008
    #10
  11. Bashar

    Bashar Notebook Evangelist

    Reputations:
    33
    Messages:
    640
    Likes Received:
    5
    Trophy Points:
    31
    W700 so far

    Bashar, Oct 24, 2008
    #11
  12. kickace

    kickace Notebook Deity

    Reputations:
    71
    Messages:
    1,054
    Likes Received:
    8
    Trophy Points:
    56
    i know the thinkpad W700 17" does....

    kickace, Oct 24, 2008
    #12
  13. djfrost2004

    djfrost2004 Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    0
    Trophy Points:
    5
    ThinkPad W700 ThinkPad W700 Photography models ThinkPad W700ds

    Up to Intel® Core™2 Quad Core Extreme Processor (2.53GHz)
    Genuine Windows Vista Ultimate

    djfrost2004, Feb 24, 2009
    #13
  14. pacmandelight

    pacmandelight Notebook Deity

    Reputations:
    260
    Messages:
    909
    Likes Received:
    0
    Trophy Points:
    30
    The T400 has a small heatsink used to cool the CPU and the GPU. Quad-core would be too hot for the current heatsink.

    pacmandelight, Feb 25, 2009
    #14
  15. mannyA

    mannyA Notebook Evangelist

    Reputations:
    36
    Messages:
    471
    Likes Received:
    0
    Trophy Points:
    30
    I love my Intel® Core™2 Quad Core Extreme Processor (2.53GHz)

    It's a thing of beauty :)

    mannyA, Feb 25, 2009
    #15
