CF19 mk8

Hi
I got really lucky and managed to get super cheap mk8 on Ebay.

xxxxxxxxxxxxxxxxxxxxxxxxxx

Another thing is after installing windows 7 touch pad is getting mad and I can't do anything, will anyone have Panasonic Windows 7 img, please?
I had it on ssd but stupidly I formatted it before I secured a copy

Please any help will be much appreciated.
Regards
Jocker01



Sorry, but forum rules prohibit any discussion of passwords.
Did you try installing the win 7 driver cab file?

ftp://ftp.panasonic.com/computer/cab/



Sorry but we can't talk about passwords on here. Please read here.
http://forum.notebookreview.com/thr...yone-who-posts-in-the-panasonic-forum.351660/

There will be ZERO TOLERANCE for anyone asking for anything having to do with how to bypass/reset passwords,



If I were to want Windows on my Toughbook, I would buy the proper restore image from Heartland Services.
It's authorized, legal, and $35 dollars shipped Fed Ex next day delivery. Best money you will ever spend if you want your Toughbook to work properly. I don't have their phone number handy, but a simple search should find them.



I tried to install drivers but it's is rather difficult as cursor keep throwing be out.
Installed win10 and is the same.
Please check this video:



I just checked and my CF19 is still under warranty until next year.
Do you think the fault is purely SW of HW issue?
I'm so pi**ed off with myself that I formatted original SSD.
Any idea how could I get hdd returned to original state?
Regards
Jocker01



Your 19 was bought cheap and most of us know why. If you want this 19 to run like a normal 19 then the only way is to send it to heartlands services for a motherboard replacement. This is the reason why we stay away from them cheap Toughbooks



Disable GPS in BIOS and send me $34 )))) joking



We don't



Use a usb mouse.
Or a usb mouse/keyboard combo.



Can't get into bios, pass protected



Tried, but only USB mouse without luck, emailed Panasonic about warranty but being a second hand not sure is warranty is still valid



In device manager make sure the touchpad/mouse driver is VERSAPAD.



Pull base and unplug GPS.



And then install gps registry patch and plug gps back.



I don't want to open a covers yet as I don't want to void my warranty (in case Panasonic will honor it).
So you think is a issue with GPS not a touchpad itself?
I just started another install of fresh windows 7 with panasonic drivers implemented by me (NTlight) if this will not work i will try install all drivers again when is installed.
I managed to get it done one and had to reinstall it as messed up drivers for WWAN.



Take hdd out, put into another pc (any), boot, install gps patch, return hdd back to mk8.



sorted, I think.....
Installed drivers through safe mode and now cursor stopped his madness.

I will try to update all drivers now as some errors showing up after booting up.



nearly done, just wwan driver now....
stragling to install it, showing in device manager MC7305.
Downloaded drivers from Panasonic website and still don't work
Any ideas?
Regards



Use search box in upper right of this screen.

Type "MC7305" and brick. I personally haven't used 7305.



Sorted
driver need to be installed though the installer provided in a file not though device manager as I tried to do it.
After that Sierra Watcher need to be downloaded and installed.
Tried on my spare sim and works as a treat.
Made myself a copy of windows with all drivers and updates installed
Now I can start to enjoy my new toy

thank you everyone who help me to get it sorted.



They didn't extract or they did extract? If you got the "this model does not support" error on extracting just use 7zip on it and it will extract it out.



Hi
Found another issue
Bluetooth connection is greyed out in wireless switch, also bluetooth symbol shows red.
I'm guessing that bluetooth module is switched off in BIOS, tried to reset CMOS by removing battery and holding the on/off switch but only got error showing bad cmos and had to setup date and time in Windows.
I had spare bluetooth module from CF19mk1 but in MK8 there is no connector for it on WWAN board, board is the same as in MK6.
Any idea how can I turn bluetooth on without accessing BIOS?
I might need to email VOLVO hoping that they will provide me with the xxxxxxx

Regards
Jocker01



Volvo, why I thought they made cars?



They are Chinese now and produce the thing we can't discuss )

Check whether bluetooth is enabled through PC Information viewer.
Maybe it's a driver issue. Intel



also make sure to have patched this before running bluetooth
https://www.armis.com/blueborne/



Just checked in PC Information viewer, BT
is disabled. Any idea how to change it without getting into Bios?

Code:

BIOS                             V8.00L11
    : BIOS Configuration               0012-0000-0005
    : Embedded Controller              V8.00L10
    : Intel(R) ME Firmware             8.1.71.3608
    : Preinstall Version               Unknown
    : Language                         English
    : System Memory                    8280552 KBytes
    : Accumulative Operating Time      300 hours
    : Touch Pad                        Enabled
    : Touchscreen                      Enabled
    : Touchscreen Mode                 Auto
    :  Current Status                  Tablet Mode
    : 10-Key Mode                      NumLock
    : CPU Power Mode                   Performance
    : Power On AC                      Disabled
    : LID Switch                       Enabled
    : Core Multi-Processing            Enabled
    : Intel(R) Hyper-Threading Technology Enabled
    : Intel(R) Virtualization Technology Enabled
    :  Intel(R) VT-d                   Disabled
    : Intel(R) Trusted Execution Technology Disabled
    : Intel(R) Turbo Boost Technology 2.0 Enabled
    : Serial Port A                    Enabled
    : Serial Port B                    Auto
    : HDD Controller Setting           AHCI
    : GPS                              Auto
    : LAN                              Enabled
    : Wireless LAN                     Enabled
    : Bluetooth                        Disabled
    : Wireless WAN                     Enabled
    : Wireless WAN ID                  10
    : Wireless Switch                  Enabled
    : Wireless Ready Indicator         Enabled
    : PC Card Slot                     Enabled
    : ExpressCard Slot                 Enabled
    : SD Slot                          Enabled
    : IEEE1394 Port                    Enabled
    : USB Port                         Enabled
    :  Left Port Setting               USB3.0
    : Port Replicator USB Port         Enabled
    : Legacy USB Support               Enabled
    : Environment                      Auto
    :  Current Status                  Normal Temperature
    : Boot Mode                        Normal
    : UEFI Boot                        Disabled
    : CSM Support                      Auto
    : Boot Option Priorities
    :  Boot Option #1                  Hard Disk
    :  Boot Option #2                  USB Floppy Disk
    :  Boot Option #3                  USB Optical Drive
    :  Boot Option #4                  LAN
    :  Boot Option #5                  USB KEY
    :  Boot Option #6                  USB Hard Disk
    : Boot Popup Menu                  Disabled
    : Password On Boot                 Disabled
    :  Password On Reboot              Same as Boot
    :  Password On Resume              Disabled
    : Boot Device On Hibernation Resume Hard Disk only
    : Supervisor Password              Enabled
    :  User Password Protection        No Protection
    :  User Password                   Disabled
    :  Hard Disk Lock                  Disabled
    : Execute-Disable Bit Capability   Enabled
    : Embedded Security (TPM) [TPM State] Enabled
    : Intel(R) ME Setup Prompt         Disabled
    : USB Configure                    Disabled
    : Concealed Mode                   Disabled
    :  Trigger Key                     Fn+F8
    : Port Replicator Status           undocked
    : Memory Slots                     2
    : Slot No. 0                       1 1 1 1 12
    :        SPD  0                    92 13 0B 03 04 21 02 01 03 52 01 08 0A 00 FE 00
    :        SPD 16                    69 78 69 30 69 11 18 81 20 08 3C 3C 00 F0 83 01
    :        SPD 32                    00 00 00 00 00 00 00 00 00 88 00 00 00 00 00 00
    :        SPD 48                    00 00 00 00 00 00 00 00 00 00 00 00 2F 11 61 00
    :        SPD 64                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 80                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 96                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 112                   00 00 00 00 00 80 AD 01 15 20 15 56 03 E7 8A E6
    :        SPD 128                   48 4D 54 34 35 31 53 36 42 46 52 38 41 2D 50 42
    :        SPD 144                   20 20 4E 30 80 AD 00 57 48 35 35 4E 35 32 38 31
    :        SPD 160                   32 30 31 54 01 11 00 00 00 00 00 11 00 00 23 C0
    : Slot No. 1                       1 1 1 1 12
    :        SPD  0                    92 11 0B 03 04 21 02 01 03 11 01 08 0A 00 FE 00
    :        SPD 16                    69 78 69 30 69 11 18 81 20 08 3C 3C 00 F0 83 05
    :        SPD 32                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 48                    00 00 00 00 00 00 00 00 00 00 00 00 2F 11 01 00
    :        SPD 64                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 80                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 96                    00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 112                   00 00 00 00 00 01 98 01 16 01 F5 0C D1 60 1A 0F
    :        SPD 128                   39 39 30 35 34 36 39 2D 31 33 36 2E 41 30 30 4C
    :        SPD 144                   46 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00
    :        SPD 160                   00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00



nope, need to go into the bios
