    Max ram for CF-M34NEFZQM?

    Discussion in 'Panasonic' started by displacedtexan, Jan 29, 2009.

  1. displacedtexan

    displacedtexan Notebook Enthusiast

    Reputations:
    13
    Messages:
    45
    Likes Received:
    1
    Trophy Points:
    16
    Anybody know what the max supported RAM is for a Mk 3 CF-M34 (CF-M34NEFZQM)?

    Google has been no help.

    Thanks!!

    displacedtexan, Jan 29, 2009
    #1
  2. Toughbook

    Toughbook Drop and Give Me 20!

    Reputations:
    1,267
    Messages:
    7,361
    Likes Received:
    370
    Trophy Points:
    251
    512MB if you look at the Panasonic Configurator...

    Toughbook, Jan 29, 2009
    #2
  3. capt.dogfish

    capt.dogfish The Curmudgeon

    Reputations:
    903
    Messages:
    2,328
    Likes Received:
    55
    Trophy Points:
    66
    Take a look at Ohlip's post on the subject in the recent CF-18 ram thread.
    CAP

    capt.dogfish, Jan 29, 2009
    #3
  4. displacedtexan

    displacedtexan Notebook Enthusiast

    Reputations:
    13
    Messages:
    45
    Likes Received:
    1
    Trophy Points:
    16
    Are you talking about config.toughbook.com? That only shows it came with up to 256mb. Is there another good site?

    Thanks!!

    displacedtexan, Jan 29, 2009
    #4
  5. Toughbook

    Toughbook Drop and Give Me 20!

    Reputations:
    1,267
    Messages:
    7,361
    Likes Received:
    370
    Trophy Points:
    251
    That is 256 BASE RAM I believe.... They don't post what it is capable of holding... Just the base RAM.

    On an side note... MOST of the CF-28s state that they are limited to 512MB of RAM.... et some work well with up to 768MB of RAM.... Experiment!

    Toughbook, Jan 29, 2009
    #5
  6. Alex

    Alex Super Moderator

    Reputations:
    4,081
    Messages:
    4,293
    Likes Received:
    10
    Trophy Points:
    106
    128mb or 256mb in the extra slot, I think for a max 384mb or 512mb total
    I have owned a few, but Teo would probably know better


    Alex

    Alex, Jan 29, 2009
    #6
  7. ludedude

    ludedude Notebook Enthusiast

    Reputations:
    21
    Messages:
    38
    Likes Received:
    0
    Trophy Points:
    15
    Snippet from my MK4 manual (not sure if it's the same for a MK3):


    Attached Files:

    ludedude, Jan 29, 2009
    #7
  8. capt.dogfish

    capt.dogfish The Curmudgeon

    Reputations:
    903
    Messages:
    2,328
    Likes Received:
    55
    Trophy Points:
    66
    As Ohlip and I believe Alex have pointed out, see the post I referenced above, some of the manuals were written before 1gig ram modules were available and that thread includes posts from several users whose machines are seeing significantly more ram than the manual says they can use. Perhaps the 512 sticks work in the CF-28s for the same reason.
    CAP
    EDIT: This thread was further back than I thought: http://forum.notebookreview.com/showthread.php?t=295436

    capt.dogfish, Jan 29, 2009
    #8
  9. tough-2-go

    tough-2-go Notebook Deity

    Reputations:
    493
    Messages:
    759
    Likes Received:
    0
    Trophy Points:
    30
    The 34 MK3 has 1 slot and no onboard RAM and is limited to 256MB or at least I have not been able to find a 512MB sodimm that works. When I tried several 512MB sodimms the laptop would only recognize half of it (256MB). :mad:

    tough-2-go, Jan 29, 2009
    #9
  10. Alex

    Alex Super Moderator

    Reputations:
    4,081
    Messages:
    4,293
    Likes Received:
    10
    Trophy Points:
    106
    You refreshed my memory on this now :confused:
    I sold my last mk-3 last summer and I remember that I was confused that the 256 add-on chip only shows up as 256 total
    I was thinking at the time that it was seeing only 1/2 of the 256 chip
    That explains the total as 256 only, as there is no onboard on this model

    Alex

    Alex, Jan 29, 2009
    #10
  11. Rob

    Rob Toughbook Aficionado

    Reputations:
    450
    Messages:
    3,941
    Likes Received:
    61
    Trophy Points:
    116
    Just an oberservation based on reading this entire thread... the OP posted about an M34, not a CF-18...

    :p

    Rob, Jan 29, 2009
    #11
  12. capt.dogfish

    capt.dogfish The Curmudgeon

    Reputations:
    903
    Messages:
    2,328
    Likes Received:
    55
    Trophy Points:
    66
    Rob,
    True enough, but the CF-M34 manual might be like the CF-28 and CF-18 manuals in its listing of max ram. As Nixon's White House used to refer to their statements of the previous day, the ram limits may be "no longer operative".
    CAP

    capt.dogfish, Jan 30, 2009
    #12
  13. displacedtexan

    displacedtexan Notebook Enthusiast

    Reputations:
    13
    Messages:
    45
    Likes Received:
    1
    Trophy Points:
    16
    Doh! I haven't had a chance to take my apart to look... work, a 14 month old, AND a wife all want attention!

    displacedtexan, Jan 30, 2009
    #13
  14. displacedtexan

    displacedtexan Notebook Enthusiast

    Reputations:
    13
    Messages:
    45
    Likes Received:
    1
    Trophy Points:
    16
    The CF-M34N indeed only has 256MB installed in a single SODIMM, none permanently soldered on.

    I'll try to find a 512MB pc100 stick and try it out!!

    displacedtexan, Jan 31, 2009
    #14
  15. ohlip

    ohlip Toughbook Modder

    Reputations:
    1,110
    Messages:
    2,358
    Likes Received:
    107
    Trophy Points:
    81



    Don't waste your time and money to do that as T-2-go said It will only recognize 256Mb even if you install 512Mb. ask me why and how I know that?


    ohlip

    ohlip, Feb 4, 2009
    #15
