    Toughbook CF-30 Overheat and shutdown

    Discussion in 'Panasonic' started by kopcicle, Oct 27, 2020.

  1. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16
    First of , I haven't been here a long time. Call it a testament to the Toughbook reliability and my increased abilities. I might actually understand *nix a bit after 25 years :)

    Now the issue:
    grep -iv ': starting\|kernel: .*: Power Button\|watching system buttons\|Stopped Cleaning Up\|Started Crash recovery kernel' \
    /var/log/messages /var/log/syslog /var/log/apcupsd* \
    | grep -iw 'recover[a-z]*\|power[a-z]*\|shut[a-z ]*down\|rsyslogd\|ups'

    ~returns,

    /var/log/syslog:Oct 27 09:38:44 kop-CF-30KQPAQ2M kernel: [ 1026.489987] thermal thermal_zone0: critical temperature reached(106 C),shutting down

    oops...

    Okay, now what ?

    ~Dennis

    P.S. pics for the hellofit


    Attached Files:

    kopcicle, Oct 27, 2020
    #1
  2. kode-niner

    kode-niner Notebook Consultant

    Reputations:
    34
    Messages:
    276
    Likes Received:
    113
    Trophy Points:
    56
    Looks like you might be due for a thermal pad overhaul.

    kode-niner, Oct 27, 2020
    #2
    steve.steve likes this.
  3. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16
    The obvious first, right? Seems to be transmitting a fair amount of heat to the case as it is.

    kopcicle, Oct 27, 2020
    #3
  4. kode-niner

    kode-niner Notebook Consultant

    Reputations:
    34
    Messages:
    276
    Likes Received:
    113
    Trophy Points:
    56
    I've only had to replace them on a CF-29 and very effectively used Fujipoly Extreme 1.5mm pads. Shouldn't be long before someone else can tell you if that would do for a CF-30 or not.

    kode-niner, Oct 27, 2020
    #4
  5. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16

    Attached Files:

    kopcicle, Oct 27, 2020
    #5
  6. Stewboy

    Stewboy Notebook Consultant

    Reputations:
    0
    Messages:
    202
    Likes Received:
    20
    Trophy Points:
    31
    Bob Johnson can help:


    Stewboy, Oct 28, 2020
    #6
    toughasnails likes this.
  7. david124124

    david124124 Newbie

    Reputations:
    0
    Messages:
    4
    Likes Received:
    1
    Trophy Points:
    5
    I've just torn my CF-30 open to do the same. Measuring the thermal pad mine was 2mm thick, the one in the video looks as thick also. I was going to order Arctic thermal pads from Amazon but decided to try the 2.0mm (CPU to Heat pipe block) & 0.5mm (Heat pipe to bottom cover) Panasonic EYG-T Graphite-PAD's instead from Digi-Key (Double heat transfer ability). Can't find much about people using them but I see that they are conductive instead of the typical non conductive style thermal pads. Wouldn't that possibly be detrimental to electrical/static protection? Using a Panasonic product to fix a Panasonic product is nice to say.

    david124124, Oct 29, 2020
    #7
  8. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16
    kopcicle, Oct 29, 2020
    #8
  9. david124124

    david124124 Newbie

    Reputations:
    0
    Messages:
    4
    Likes Received:
    1
    Trophy Points:
    5
    That's it. It's next day shipping so I'll post how it works by tomorrow with a few photos.

    david124124, Oct 30, 2020
    #9
  10. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16
    I won't be able to get into mine until next week :-( I have a bit of a boggle going on here.


    Attached Files:

    kopcicle, Oct 30, 2020
    #10
  11. kopcicle

    kopcicle Notebook Enthusiast

    Reputations:
    0
    Messages:
    33
    Likes Received:
    1
    Trophy Points:
    16
    watch -n 2 sensors
    Screenshot at 2020-10-31 14-04-33.png
    So far so good. The local surplus store donated a parts CF-30.
    I just stuffed a second piece of material from the roached machine on top of the existing pad and bolted it back together.
    A whole lot better than 106 degree Celsius shutdowns :)

    Now back to the 4G32 Mitsubishi....

    kopcicle, Oct 31, 2020
    #11
    kode-niner likes this.
  12. david124124

    david124124 Newbie

    Reputations:
    0
    Messages:
    4
    Likes Received:
    1
    Trophy Points:
    5
    Right on, good to hear.

    The new pads worked perfectly for the CF-30 Mk1.

    2mm for the CPU block and 0.5mm for the heat pipe to case. One thing I did notice is the longer heat pipe was not making full contact with the case when screwed down (from factory or bent later).

    After bending the heat pipe just slightly near the cpu block, it now sits flush & making full contact along the bottom.

    I ordered the smaller pads 35mmx35mm and have 1/2 of the uncut pads left after doing my CF-29 mk3 also.

    [​IMG] [​IMG] [​IMG] [​IMG]
     [​IMG]

    Last edited: Nov 1, 2020
    david124124, Nov 1, 2020
    #12
    toughasnails likes this.
