    WWAN dip switches

    Discussion in 'Panasonic' started by Shawn, Jul 11, 2014.

  1. Shawn

    Shawn Crackpot Search Ninja and Options Whore

    Reputations:
    1,541
    Messages:
    8,306
    Likes Received:
    2,050
    Trophy Points:
    331
    Anyone know what exactly they do?
    I mean a semi technical explanation.
    Do they change the data rate or frequency ???
    How do they affect the USB port connected to the WWAN mini PCI-E slot?








    3 and counting down..

    Shawn, Jul 11, 2014
    #1
  2. Toughbook

    Toughbook Drop and Give Me 20!

    Reputations:
    1,267
    Messages:
    7,361
    Likes Received:
    370
    Trophy Points:
    251
    Shawn,

    There have been many explanations over the years... But mine have always been set perfect form the factory. BUT... If you are switching modems... You need to change the DIP switches.

    Teo will probably chime in and save the day....

    Toughbook, Jul 12, 2014
    #2
  3. Shawn

    Shawn Crackpot Search Ninja and Options Whore

    Reputations:
    1,541
    Messages:
    8,306
    Likes Received:
    2,050
    Trophy Points:
    331
    I'm not using a modem. I am attempting a GPS.

    Shawn, Jul 13, 2014
    #3
  4. BaRRmaley

    BaRRmaley Notebook Deity

    Reputations:
    206
    Messages:
    1,451
    Likes Received:
    489
    Trophy Points:
    101
    I'm sure nobody knows the answer.
    Even responsible Panasonic engineers were drown in an ocean :))

    BaRRmaley, Jul 13, 2014
    #4
  5. ohlip

    ohlip Toughbook Modder

    Reputations:
    1,110
    Messages:
    2,358
    Likes Received:
    107
    Trophy Points:
    81
    It is to identify and activate the CDMA or GSM network. Google the difference between the GSM and CDMA network and you will find the answer.

    ohlip

    ohlip, Jul 15, 2014
    #5
  6. Shawn

    Shawn Crackpot Search Ninja and Options Whore

    Reputations:
    1,541
    Messages:
    8,306
    Likes Received:
    2,050
    Trophy Points:
    331
    So why does it matter where they are set when I install a mini pcie GPS in the WWAN slot?

    I'm .guessing that it has to do with bandwidth or datastream

    Shawn, Jul 16, 2014
    #6
  7. kode-niner

    kode-niner Notebook Consultant

    Reputations:
    34
    Messages:
    276
    Likes Received:
    113
    Trophy Points:
    56
    [​IMG]

    Seriously need to know.


    Attached Files:

    kode-niner, Aug 19, 2014
    #7
    Shawn and ADOR like this.
  8. kode-niner

    kode-niner Notebook Consultant

    Reputations:
    34
    Messages:
    276
    Likes Received:
    113
    Trophy Points:
    56
    Fiddled around with the switches yesterday in a CF-19 and a Huawei EM820U. I could get a Serial enable/disable indented sub-menu to appear or disappear in BIOS under WWAN enable/disable, which I presume is the GPS, while still keeping the WWAN working.

    kode-niner, Aug 20, 2014
    #8
  9. kode-niner

    kode-niner Notebook Consultant

    Reputations:
    34
    Messages:
    276
    Likes Received:
    113
    Trophy Points:
    56
    Playing around some more with the dip switches today on a CF-19 MK2 has revealed that some positions will either power up the WWAN radio during POST (front LED is on), will not light up but during POST but wait for the software to activate it, or will not work at all. Of course this is with the side radio switched on.

    Another interesting observation that is related to the above is that Linux can better deal with the radio off than Windows. If it is not completely on with the front LED lit before launching the software, the Mobile Partner software I'm using to connect will think the module is disabled. I experienced this with ON-ON-ON-OFF. Linux network-manager will fire it up no problems.

    It's confusing but I believe with time and patience we should be able to figure this out.

    kode-niner, Aug 31, 2014
    #9
    Shawn likes this.
  10. ADOR

    ADOR Evil Mad Scientist

    Reputations:
    520
    Messages:
    1,941
    Likes Received:
    208
    Trophy Points:
    81
    On models like the T/W5,7,8 series you only have 2 dip switches.

    ADOR, Aug 31, 2014
    #10
