    Schenker Via 14. Is it a new clevo?

    Discussion in 'Sager and Clevo' started by sicily428, Jul 20, 2017.

  1. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    Schenker Via 14
    https://www.mysn.de/via-laptops/schenker-via14


    DISPLAY
    14" (35,6 cm) Full HD (1920 × 1080) Non-Glare IPS
    Maximum opening angle 135°.
    CHIPSET
    Intel Sunrise Point – LP
    PROCESSOR
    The Processor in the SCHENKER VIA 14 is based on Intel Kabylake-U technology. The following Processor is available:

    Intel Core i5-7Y54 - 1,2 - 3,2 GHz 4MB 4,5W TDP

    The Processor is soldered. Upgrades are therefore not possible.
    GRAPHICS
    The graphics card in the SCHENKER VIA 14 is integrated into the CPU:
    • Intel® HD Graphics 615
      Features: DirectX® 12, OpenGL 4.4, QuickSync, Intel InTru, Intel Clear-Video-Technic
    The SCHENKER VIA 14 supports the following maximum resolutions:
    • intern: 1920*1080@60Hz
    • HDMI: 3840x2160@25Hz or 2560x1440@60Hz/li>
    • VGA: depending on the quality of the display
    Up to 2 displays can be operated simultaneously: 1x internal, 1x external. The operation of 2 external monitors is not possible without additional device.
    No optical drive
    AUDIO
    Realtek ALC269 High Definition Audio, 2 Speakers, Internal Microphone
    KEYBOARD
    Keyboard with white backlighting
    TOUCHPAD
    Touchpad with Multi-gesture and Scroll Function
    CONNECTIVITY
    1 x Micro-SD Cardreader
    2 x USB 2.0
    1 x USB 3.0
    1 x USB 3.0 (Type-C, including Displayport)
    1 x Micro-HDMI (HDMI 1.4b)
    1 x Headphone-Jack br/> 1 x Microphone-Jack
    NETWORKING
    Intel WLAN AC8260 incl. Bluetooth 4.0, 720p Webcam
    DIMENSIONS
    340 x 235 x 17 mm (W x D x H)
    WEIGHT
    1.49
    BATTERY
    Li-Polymer 5400mAh (up to 10hr general use)
    POWER SUPPLY
    36W Power Supply
    IN THE BOX
    SCHENKER VIA 14 Laptop, Power Supply + Cable, microHDMI to HDMI Adapter, USB Stick with drivers, Driver CD, Manual





    Is it a new clevo?

    Last edited: Jul 20, 2017
    sicily428, Jul 20, 2017
    #1
  2. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    @XMG
    do you have more infos?

    sicily428, Jul 20, 2017
    #2
  3. cj_miranda23

    cj_miranda23 Notebook Evangelist

    Reputations:
    334
    Messages:
    567
    Likes Received:
    537
    Trophy Points:
    106
    http://forum.notebookreview.com/threads/what-clevo-model-is-this.801705/

    cj_miranda23, Jul 20, 2017
    #3
    sicily428 likes this.
  4. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    Last edited: Jul 20, 2017
    sicily428, Jul 20, 2017
    #4
  5. Ionising_Radiation

    Ionising_Radiation ?v = ve*ln(m0/m1)

    Reputations:
    762
    Messages:
    3,242
    Likes Received:
    2,675
    Trophy Points:
    231
    @sicily428—looks like the Clevo N240BU. Pretty standard ultrabook, MacBook Air type of machine.

    Give me Ryzen 7 and an MXM 3.0A GTX 1050 Ti...

    Sent from my HTC 10 using Tapatalk

    Ionising_Radiation, Jul 20, 2017
    #5
  6. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    I think that a laptop like a w650kk1 with a i7-7700 or a Ryzen and a gtx1050ti/m2200 mxm 3.0a could be a really good laptop

    sicily428, Jul 21, 2017
    #6
  7. W00d_m3

    W00d_m3 Notebook Enthusiast

    Reputations:
    10
    Messages:
    24
    Likes Received:
    14
    Trophy Points:
    6
    W00d_m3, Jul 21, 2017
    #7
    sicily428 likes this.
  8. XMG

    XMG Company Representative

    Reputations:
    749
    Messages:
    1,755
    Likes Received:
    2,200
    Trophy Points:
    181
    The S306 is/was a TopStar chassis. The company hasn't actually closed, it's all pretty complicated and I can't divulge information about it in public.

    But the VIA 14 is not a Clevo chassis, nor is it a Top Star chassis.....

    XMG, Jul 23, 2017
    #8
    4004 and sicily428 like this.
  9. Meaker@Sager

    Meaker@Sager Company Representative

    Reputations:
    9,436
    Messages:
    58,194
    Likes Received:
    17,909
    Trophy Points:
    931
    Except you can open these types of machines and replace the ram/storage with standard parts.

    Meaker@Sager, Jul 23, 2017
    #9
  10. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    I asked for my thread about clevos. thanks for your answer. :)

    sicily428, Jul 24, 2017
    #10
    XMG likes this.
  11. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    is this a fanless laptop?

    sicily428, Aug 11, 2017
    #11
  12. XMG

    XMG Company Representative

    Reputations:
    749
    Messages:
    1,755
    Likes Received:
    2,200
    Trophy Points:
    181
    Correct, 100% passive!

    XMG, Aug 13, 2017
    #12
    sicily428 likes this.
  13. sicily428

    sicily428 Donuts!! :)

    Reputations:
    816
    Messages:
    3,610
    Likes Received:
    1,988
    Trophy Points:
    231
    thanks!

    sicily428, Aug 14, 2017
    #13
    XMG likes this.
  14. picolino

    picolino Notebook Consultant

    Reputations:
    10
    Messages:
    159
    Likes Received:
    30
    Trophy Points:
    41
    How does this compare with the Schenker s306 performance-wise? In particular, how does i5 7y54 compare with i5 6200U?

    I own the s306 for 5 months now and it has been very good so far. Office work is a breeze and I can even run some benchmarks overnight on a single core; I found that a turbo CPU frequency of 2.7 GHz can be maintained for hours as long as the laptop remains cool enough (which it does) and it is not used for anything else. If I remember correctly, the power (rate) during my benchmarks is around 11 W (with every other program closed), well, in any case, it is lower than the TDP of 15 W.

    However, the TDP for i5 7y54 is set at 4.5 W, which is crazy low. I do not expect that this will have an impact on office work, but it may render some mild benchmarking impossible.

    Any thoughts?

    picolino, Sep 6, 2017
    #14
  15. XMG

    XMG Company Representative

    Reputations:
    749
    Messages:
    1,755
    Likes Received:
    2,200
    Trophy Points:
    181
    The 7Y54 is a little faster than the 6200U in single threaded benchmarks, around 15% slower in multi threaded benchmarks - this would translate reasonably accurately to real world usage. It is a difference, but it's not like either laptop is designed to break benchmarks. You're talking about unzipping a file that takes a minute on the 6200U taking 50 seconds with the 7Y54 - if anyone is really hitting the CPU with heavy batch editing for example then an HQ or K CPU is where you want to be ;-)

    XMG, Sep 8, 2017
    #15
  16. picolino

    picolino Notebook Consultant

    Reputations:
    10
    Messages:
    159
    Likes Received:
    30
    Trophy Points:
    41
    Thank you for your answer :)

    It is certainly not a benchmarking laptop, but for the kind of benchmarking that I perform, where I just need stable turbo frequency on a single core for some tens of minutes, it is more than enough. Judging by the results in single threaded benchmarks ( http://cpu.userbenchmark.com/Compare/Intel-Core-i5-7Y54-vs-Intel-Core-i5-6200U/m193628vsm36796), it seems to me that the 7Y54 is indeed capable of maintaining turbo frequency on a single core for some tens of minutes. Do you have perhaps hands-on experience to verify that?

    picolino, Sep 8, 2017
    #16
