    Touchpad doesn't work while typing?

    Discussion in 'Samsung' started by alexpato111, Dec 24, 2011.

  1. alexpato111

    alexpato111 Newbie

    Reputations:
    0
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    5
    i'm having a bit of trouble trying to get my NP305E5A-A01US laptop to work while pressing keys. i've gone to control panel and looked through the mouse/elan touchpad's settings, but nothing i do will get it to work. help would be very much appreciated :)

    alexpato111, Dec 24, 2011
    #1
  2. alexpato111

    alexpato111 Newbie

    Reputations:
    0
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    5
    36 views? come on one of you must have some sort of input :D

    alexpato111, Dec 24, 2011
    #2
  3. Luterin

    Luterin Notebook Evangelist

    Reputations:
    36
    Messages:
    400
    Likes Received:
    5
    Trophy Points:
    31
    My guess is that no one else have those problems. Atleast I don't. And it really doesn't feel like its a hardware issue either, so I am guessing you installed something that messed things up. Or perhaps changed some setting by misstake, but no idea which, since I've never seen or heard about anything like this before.

    Luterin, Dec 24, 2011
    #3
  4. alexpato111

    alexpato111 Newbie

    Reputations:
    0
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    5
    well this laptop is straight out of the box so i haven't installed anything that would affect this sort of thing. the thing is that i've googled this problem and on other computers there are simple, simple ways to fix this problem but i cannot find a way to do the same on my computer.

    alexpato111, Dec 24, 2011
    #4
  5. Luterin

    Luterin Notebook Evangelist

    Reputations:
    36
    Messages:
    400
    Likes Received:
    5
    Trophy Points:
    31
    I never heard anything simillar to this, so something is wrong. Perhaps just call where you bought it and ask them, and possibly get it replaced if it brand new.

    Luterin, Dec 24, 2011
    #5
  6. John Ratsey

    John Ratsey Moderately inquisitive Super Moderator

    Reputations:
    7,197
    Messages:
    28,841
    Likes Received:
    2,166
    Trophy Points:
    581
    I'm a little unclear exactly what your problem is. Could you explain it better.

    Most touchpads have a "palm check" option to briefly disable it while people are typing (otherwise the cursor may move if, for example, a thumb accidentally brushes the touchpad).

    John

    John Ratsey, Dec 25, 2011
    #6
  7. alexpato111

    alexpato111 Newbie

    Reputations:
    0
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    5
    it's alright, i figured it out. i found some elan drivers on google that fixed the problem

    alexpato111, Dec 25, 2011
    #7
  8. normskilight

    normskilight Newbie

    Reputations:
    0
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    5
    I'm having this problem too while playing games.
    It seems to be an intended feature to stop the user dragging the mouse about while typing.
    However the control panel settings for the current drivers I have (10.0.7.3)
    don't seem to have an option to disable this (if there is, they have done a top job on hiding it).
    Palm tracking should be enough, I feel this additional feature to disable all movement whilst any typing is taking place seems a bit much.

    Could you link me to the place you acquired the alternative drivers or if that not allowed could you quote me what I should Google to find it, thanks in advance.

    normskilight, Dec 25, 2011
    #8
  9. alexpato111

    alexpato111 Newbie

    Reputations:
    0
    Messages:
    5
    Likes Received:
    0
    Trophy Points:
    5
    i just typed in ' samsung NP305E5A-A01US touchpad ' and the elan drivers popped up.

    alexpato111, Dec 25, 2011
    #9
  10. normskilight

    normskilight Newbie

    Reputations:
    0
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    5
    Thanks for the response however using an old driver just doesn't sit well with me.
    so..... I've had a play and found the correct registry entry to change.

    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\OtherSetting\DisableWhenType_DelayTime_Move

    mine was "5dc" which is hexadecimal for 1500 or one and a half seconds.

    I set it to 0 and rebooted and now I can hold down keys and continue to use the touch-pad.

    I thought at first the registry entry "DisableWhenType_Enable" was the way to tackle this but changing this had no effect, this may be why we don't have a tick box for this option in our control panels yet. Hopefully they fix this and add this feature soon.

    Hope this helps someone.

    Steve.

    normskilight, Dec 25, 2011
    #10
  11. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    Has anyone had success using alt+tab while dragging? It works for me on other systems, but not this one. An example use case is dragging something from one application, using alt+tab to switch to another for the release. Pressing alt+tab kills the drag on the Samsung.

    sean.e, Jan 5, 2012
    #11
  12. Luterin

    Luterin Notebook Evangelist

    Reputations:
    36
    Messages:
    400
    Likes Received:
    5
    Trophy Points:
    31
    You should be able to drag to other applications by holding the object over the right program on the taskbar at the bottom.

    Luterin, Jan 5, 2012
    #12
  13. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    Yes, that works but is not something I remember to do on this system.

    sean.e, Jan 5, 2012
    #13
  14. danmarell

    danmarell Notebook Enthusiast

    Reputations:
    0
    Messages:
    11
    Likes Received:
    0
    Trophy Points:
    5
    I have disable two finger scrolling because of the delay. I instead have enabled the option for the right side of the trackpad to do one finger scrolling which is immediate.

    I dont want to have to hack the registry to be able to scroll without a delay.

    danmarell, Jan 8, 2012
    #14
  15. yknyong1

    yknyong1 Radiance with Radeon

    Reputations:
    1,191
    Messages:
    2,095
    Likes Received:
    8
    Trophy Points:
    56
    After finish scrolling, I noticed that we still have to tap once to stop scrolling.

    yknyong1, Jan 8, 2012
    #15
  16. skye19881230

    skye19881230 Newbie

    Reputations:
    0
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    5
    Yes, I think so.

    skye19881230, Jan 9, 2012
    #16
  17. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    ahhh - it works as expected if you use the drag and drop gesture without using the button-click. That is, instead of using click+drag, use double-tap+drag (One finger drag and drop needs to be enabled in the touchpad control panel). Then alt+tab works while dragging.

    sean.e, Jan 11, 2012
    #17
  18. danimal4326

    danimal4326 Newbie

    Reputations:
    0
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    5
    Ok, I've been poking around the registry settings and found some usefull stuff


    Go into HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\UIFunctionOption

    Change the value for "UI_Theme" to 0 or 1 to get more options in the UI.
    I like the version for "1".

    It gives you options for 3 finger tapping, changing the click modes (left and right), palm tracking, and sensitivity!

    Make sure to have the "Mouse" control panel closed. If you have it open, close and re-open then go to the Elan settings.

    Version 2 is for DELL and doesn't work. I think it expect another app to be there to change settings.

    Version 3 is UltraNav ??

    Version 4 is the default samsung settings

    Anything 5 or above gives you the same as "0"

    danimal4326, Jan 14, 2012
    #18
  19. Loweack

    Loweack Notebook Enthusiast

    Reputations:
    2
    Messages:
    40
    Likes Received:
    0
    Trophy Points:
    15
    Excellent!! Thank you very much!

    Loweack, Jan 14, 2012
    #19
  20. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    Fantastic! Nice sleuthing.

    sean.e, Jan 14, 2012
    #20
  21. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    Just found something: regardless of what theme you have selected in the registry, you can directly launch themes 1 and 4 via the exes in \Program Files\ElanTech.

    Theme 4 is C:\Program Files\Elantech\ETDSimpleUI.exe.
    Theme 1 is C:\Program Files\Elantech\ETDAniConf.exe.

    sean.e, Jan 14, 2012
    #21
  22. Luterin

    Luterin Notebook Evangelist

    Reputations:
    36
    Messages:
    400
    Likes Received:
    5
    Trophy Points:
    31
    Which drivers are these for? 10.7.5.0 or 10.0.7.3?

    Luterin, Jan 14, 2012
    #22
  23. yknyong1

    yknyong1 Radiance with Radeon

    Reputations:
    1,191
    Messages:
    2,095
    Likes Received:
    8
    Trophy Points:
    56
    In 10.0.7.3 it does not have this function (UI_theme is not there).

    This means Elan drivers will possibly employ filtering techniques from now on.

    yknyong1, Jan 15, 2012
    #23
  24. undeserve

    undeserve Newbie

    Reputations:
    0
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    5
    Hi all,

    Just picked up my Chronos a few days ago and been fiddling around with the mouse. The auto-update sucked so I went only and found a driver version 10.7.6.2 WHQL. I've found that I cant move the cursor while typing. It seems to be a problem some other people have and I can't find a way to get it to work.

    I've tried regedit. I've set all of the following values to 0 but no luck yet:
    Elantech/Smartpad/
    DisableWhenType_AllArea
    DisableWhenType_DelayTime_Gesture
    DisableWhenType_DelayTime_Move
    DisableWhenType_DelaTime_Tap
    DisableWhenType_Enable

    I also tried setting Elantech/UIFunctionOption/UI_Theme to 0 but that didn't do anything so I set that back to 4.

    Anyone know any way to set things so that I can use the trackpad while typing? Or is there a version of the driver that might be better?

    undeserve, Mar 21, 2012
    #24
  25. sean.e

    sean.e Notebook Consultant

    Reputations:
    12
    Messages:
    138
    Likes Received:
    0
    Trophy Points:
    30
    Change the TouchPadRejection_Display value from 255 to 1 at HKEY_CURRENT_USER\Software\Elantech\SmartPadDisplay. Then start ETDAniConf.exe. On the Additional tab, disable rejection. (I have 10.7.11.5 installed.)

    sean.e, Mar 21, 2012
    #25
  26. SpHeRe31459

    SpHeRe31459 Newbie

    Reputations:
    0
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    5
    I found that for me on my RV520 (which shipped with just terribly buggy old Elan drivers) that I've updated to 10.7.6.2, I can set

    HKEY_CURRENT_USER\Software\Elantech\SmartPad
    "DisableWhenType_Enable"=dword:00000000

    And I just tested it and it will stick through reboots.

    SpHeRe31459, Apr 19, 2012
    #26
  27. timvwcom

    timvwcom Newbie

    Reputations:
    0
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    5
    The C:\Program Files\Elantech\ETDAniConf.exe tip was $$$ for allowing me to set the advanced touchpad settings on my Samsung Series 7 NP700Z5B-S01UB. :you rock:

    timvwcom, Jun 14, 2012
    #27
  28. alexsickkid

    alexsickkid Notebook Enthusiast

    Reputations:
    0
    Messages:
    14
    Likes Received:
    0
    Trophy Points:
    5
    Using the latest driver with no luck on anything above, anybody find any other solutions?

    alexsickkid, Jul 27, 2012
    #28
  29. John Ratsey

    John Ratsey Moderately inquisitive Super Moderator

    Reputations:
    7,197
    Messages:
    28,841
    Likes Received:
    2,166
    Trophy Points:
    581
    Isn't the fix to go into the registry, find DisableWhenType_Enable and change it from 1 to 0? There are innumerable other touchpad settings in HKEY_CURRENT_USER\Software\Elantech\GroupOption\SmartPad.

    John

    John Ratsey, Jul 27, 2012
    #29
  30. dopplur

    dopplur Newbie

    Reputations:
    0
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    5
    I created a forum account just to say thank you! Although my directory was slightly different:

    1) regedit.exe 2) HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad

    EDIT: Although that directory works, I found it didn't fix my problem. Here's my solution:

    Get an older driver. For whatever reason, the latest one seems to create too many problems and the older one simply works better. Heck, it even looks better! Here's a link to the download that worked for me:

    ElanTech Touchpad Driver 8.0.7.0 - TechSpot Drivers

    dopplur, Aug 31, 2012
    #30
  31. Quarien

    Quarien Newbie

    Reputations:
    0
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    5
    Hi. I have the same problem with disabled touchpad. I tried most of your solutions - nothing works.

    1. Under HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\ there is no "Elantech" folder.
    However, "DisableWhenType..." keys are in HKEY_LOCAL_MACHINE/SOFTWARE/Elantech/SmartPad and I set everything to 0.
    [​IMG]

    Nope. doesn't work.

    2.
    Might work for me, however, my ETDAniConf.exe looks like this:



    This is the main reason, why I am fighting with regedit.exe...

    My driver version is 11.14.1.3_WHQL.
    Is is the only one that works with Windows 8 gestures, so I don't really feel like reinstaling it. I tried to fix that windows on the first place, but this is hopeless.

    Quarien, Jan 28, 2013
    #31
  32. John Ratsey

    John Ratsey Moderately inquisitive Super Moderator

    Reputations:
    7,197
    Messages:
    28,841
    Likes Received:
    2,166
    Trophy Points:
    581
    Did you do a registry search for "DisableWhenType" to see if there is another set of the entries? I'm finding that string in all these places on my Windows 7 X4C:

    HKEY_CURRENT_USER\Software\Elantech\GroupOption\SmartPad
    HKEY_CURRENT_USER\Software\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Control\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Control\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Control\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\services\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\Control\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\Control\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\Control\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\services\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\services\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\ControlSet002\services\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Elantech\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\services\Elantech\GroupOption\GroupMap_ETD0B00\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\services\Elantech\GroupOption\GroupMap_ETD0B01\SmartPad
    HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\services\Elantech\SmartPad
    HKEY_USERS\S-1-5-21-2273624540-2494411189-709609350-1000\Software\Elantech\GroupOption\SmartPad
    HKEY_USERS\S-1-5-21-2273624540-2494411189-709609350-1000\Software\Elantech\SmartPad

    :confused: :eek: I wonder if Elantech can't make up their minds where to put their entries.

    I'm not an expert on how the registry works but I would expect the current user and current control set entries to be the most important.

    John

    John Ratsey, Jan 28, 2013
    #32
  33. Quarien

    Quarien Newbie

    Reputations:
    0
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    5
    Code:
    HKEY_USERS\S-1-5-21-2273624540-2494411189-709609350-1000\Software\Elantech\SmartPad
    Like... I don't even...
    I have no idea, but this is the only one key that I had similar to your list and it worked. Thanks!

    Quarien, Jan 28, 2013
    #33
