    What kind of screw is this?

    Discussion in 'Toshiba' started by jbritt123, Sep 28, 2008.

  1. jbritt123

    jbritt123 Newbie

    Reputations:
    0
    Messages:
    6
    Likes Received:
    0
    Trophy Points:
    5
    I'm trying to take apart my Toshiba Qosmio G25 and came across this screw (see pic) underneath in the battery compartment area... anyone know what type of screw this is and where i can get the screwdriver? (I've checked at Radio Shack but no luck) Never seen anything like it... star pattern with a little bump in the centre... weird.

    Thanks for any help...


    Attached Files:

    • test.JPG
      File size:
      242.8 KB
      Views:
      123
    jbritt123, Sep 28, 2008
    #1
  2. gengerald

    gengerald Technofile Extraordinaire

    Reputations:
    674
    Messages:
    1,961
    Likes Received:
    0
    Trophy Points:
    55
    Looks like you may have to make a screwdriver into that configuration with a dremel or grinding wheel.

    gengerald, Sep 28, 2008
    #2
  3. sesshomaru

    sesshomaru Suspended Disbelief!

    Reputations:
    316
    Messages:
    1,918
    Likes Received:
    1
    Trophy Points:
    56
    That's a T3.5 or T4 head you are looking for. Pic attached..


    Attached Files:

    sesshomaru, Sep 28, 2008
    #3
  4. steveninspokane

    steveninspokane John 14:6 - Only ONE Way!

    Reputations:
    732
    Messages:
    1,672
    Likes Received:
    0
    Trophy Points:
    55
    T for Torq.

    steveninspokane, Sep 28, 2008
    #4
  5. K-TRON

    K-TRON Hi, I'm Jimmy Diesel ^_^

    Reputations:
    4,412
    Messages:
    8,077
    Likes Received:
    2
    Trophy Points:
    205
    I think its a T4 or T6. Those are pretty much the standard torx used on laptops.

    You need a "keyed" torx screwdriver.

    The term "keyed" is used because the screw has a small metal cylinder in the middle, to prevent it from being taken out.

    They sell keyed torx screwdrivers, they are just a little harder to find.
    Just make sure the screwdriver you get has a hole in the end, so that the key can fit into the end of the screw

    K-TRON

    K-TRON, Sep 28, 2008
    #5
  6. gadgetmind

    gadgetmind Newbie

    Reputations:
    0
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    5
    It's one of the many flavours of "security" Torx screws. You need a set of security Torx hex bits to fit to into screwdriver body - lots of them on eBay and they are very cheap and you get a wide range of bits.

    If you haven't got a screwdriver body that takes hex bits, then get one! Or ideally a large ratchet one and a smaller fixed "stubby"

    All-in-one screwdrivers are now something I only use when working on car engines. I've dropped too many hex bits into the darkness ...

    Ian

    gadgetmind, Sep 28, 2008
    #6
