    RTX 3000 tested in AW18

    Discussion in 'Alienware 18 and M18x' started by razor0601, Jun 3, 2020.

  1. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    Today my HP RTX 3000 arrived. In SG-Mode it works fine in AW18. But installing this card is a disaster. For testing I took an M18X R2 Heatsink, because with AW18 Heatsink I need a dremel. It doesn’t sit very well on the card. The next thing is how to get this card sitting perfectly on the MXM slot. The mounting holes are displaced. So I have to build a bracket to hold the card. But the good thing is the card is @stock as fast as a P5000/1070 and works with the newest driver(mod.inf)


    Attached Files:

    razor0601, Jun 3, 2020
    #1
    TBoneSan, @tomX, Ashtrix and 11 others like this.
  2. Maxware79

    Maxware79 Alienware died in 2014

    Reputations:
    218
    Messages:
    1,277
    Likes Received:
    944
    Trophy Points:
    131
    Great work! I'd love to see how it fits in the M18x and Ranger.
    +REP

    Maxware79, Jun 3, 2020
    #2
  3. Clamibot

    Clamibot Notebook Deity

    Reputations:
    645
    Messages:
    1,132
    Likes Received:
    1,566
    Trophy Points:
    181
    This is awesome! Was a VBIOS mod required? You plugged it in and it just worked? My mouth is watering for just one more upgrade on my Ranger.

    Just... One... More... Upgrade!!!

    Clamibot, Jun 3, 2020
    #3
  4. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    No VBIOS mod was required. I plugged in, Bios showed the card and it worked.

    razor0601, Jun 4, 2020
    #4
    M18x-oldie likes this.
  5. Sentential

    Sentential Notebook Evangelist

    Reputations:
    76
    Messages:
    328
    Likes Received:
    272
    Trophy Points:
    76
    The fact that his is possible is a testament to how far Workstations have fallen.

    Sentential, Jun 4, 2020
    #5
  6. Clamibot

    Clamibot Notebook Deity

    Reputations:
    645
    Messages:
    1,132
    Likes Received:
    1,566
    Trophy Points:
    181
    I'm frustrated with the stupidity of all the companies that abandoned standard MXM. If HP can fit these Quadro cards onto a card almost exactly the size of standard MXM 3.0B board, there's no reason everyone needed to go off and make their own weird cards.

    At least I know for certainty now that I can perform at least one more upgrade on my Ranger.

    Clamibot, Jun 4, 2020
    #6
    Ashtrix, TBoneSan and M18x-oldie like this.
  7. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    The only thing you have to do is modify your Heatsink and maybe build a bracket to hold the card.

    razor0601, Jun 4, 2020
    #7
    M18x-oldie likes this.
  8. Baddemichl

    Baddemichl Notebook Consultant

    Reputations:
    21
    Messages:
    118
    Likes Received:
    136
    Trophy Points:
    56
    Nice.
    Could you do same 3dMark benchmarks like Firestrike and Timespy, please.

    Baddemichl, Jun 5, 2020
    #8
    M18x-oldie and Rengsey R. H. Jr. like this.
  9. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    I only have Superposition and now I am testing this card in Precision M6700

    razor0601, Jun 5, 2020
    #9
    TruenoG7, UltraGSM and M18x-oldie like this.
  10. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    Next days I‘m trying to mod the Heatsink to get this card fully working.

    razor0601, Jun 7, 2020
    #10
    M18x-oldie likes this.
  11. ll_r1d0_ll

    ll_r1d0_ll Notebook Evangelist

    Reputations:
    33
    Messages:
    340
    Likes Received:
    51
    Trophy Points:
    41
    You can try getting the Z book's heatsink ( Which came with RTX 3000 ) and remove the copper pipes from it and attach the ones from you AW 18's heatsink by using hot air gun . Atleast you will have proper fitting that way. It isnt that much risky i would say

    ll_r1d0_ll, Jun 8, 2020
    #11
  12. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    Which Zbook is that ?

    razor0601, Jun 8, 2020
    #12
  13. ll_r1d0_ll

    ll_r1d0_ll Notebook Evangelist

    Reputations:
    33
    Messages:
    340
    Likes Received:
    51
    Trophy Points:
    41
    ll_r1d0_ll, Jun 8, 2020
    #13
  14. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    That GPU in there looks like a normal MXM 3.0 card

    razor0601, Jun 8, 2020
    #14
    M18x-oldie likes this.
  15. ll_r1d0_ll

    ll_r1d0_ll Notebook Evangelist

    Reputations:
    33
    Messages:
    340
    Likes Received:
    51
    Trophy Points:
    41
    yeah but there is a difference in the heatsink if you can see closely .. i mean the fitting and the ups and downs for Coils , Vrms etc

    ll_r1d0_ll, Jun 8, 2020
    #15
    M18x-oldie likes this.
  16. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    I think it’s easier to mod the AW18 Heatsink. Seems to be easier than modding for a MSI 1070. Only thing I have to think about is how I mount the card on the board.

    razor0601, Jun 8, 2020
    #16
    M18x-oldie likes this.
  17. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    It’s done.


    Attached Files:

    razor0601, Jun 30, 2020
    #17
    @tomX, Semmy, Ashtrix and 5 others like this.
  18. Maxware79

    Maxware79 Alienware died in 2014

    Reputations:
    218
    Messages:
    1,277
    Likes Received:
    944
    Trophy Points:
    131

    Maxware79, Jun 30, 2020
    #18
  19. M18x-oldie

    M18x-oldie Notebook Evangelist

    Reputations:
    14
    Messages:
    385
    Likes Received:
    129
    Trophy Points:
    56
    M18x-oldie, Jul 2, 2020
    #19
  20. devilhunter

    devilhunter Notebook Evangelist

    Reputations:
    120
    Messages:
    361
    Likes Received:
    254
    Trophy Points:
    76
    Does this work with RTX 5000? and how does this perform under benchmarks?

    devilhunter, Jul 21, 2020
    #20
  21. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    I think it will work. But you need the 100w Heatsink from M18X R2.

    razor0601, Jul 21, 2020
    #21
  22. devilhunter

    devilhunter Notebook Evangelist

    Reputations:
    120
    Messages:
    361
    Likes Received:
    254
    Trophy Points:
    76
    That's way too cool.

    Wonder if 4940mx is a bottle necking. I do have a mint Alienware 18 maxed out, I wonder if I should sell it or experiment on it.

    devilhunter, Jul 21, 2020
    #22
  23. ssj92

    ssj92 Neutron Star

    Reputations:
    2,446
    Messages:
    4,446
    Likes Received:
    5,690
    Trophy Points:
    581
    Overclocked 4940MX should not bottleneck even RTX 5000, unless you play some game that is super CPU reliant. Even then you should be getting very good performance.

    ssj92, Jul 21, 2020
    #23
  24. M18x-oldie

    M18x-oldie Notebook Evangelist

    Reputations:
    14
    Messages:
    385
    Likes Received:
    129
    Trophy Points:
    56
    Should work.

    I remember @Baddemichl tested the RTX 5000 in m18x r2, but he wasn't satisfied with the performance outcome, I think.

    Also it's a mess they changed the position of the fixing hole

    M18x-oldie, Jul 21, 2020
    #24
  25. Clamibot

    Clamibot Notebook Deity

    Reputations:
    645
    Messages:
    1,132
    Likes Received:
    1,566
    Trophy Points:
    181
    The RTX 5000 was power limited to 80 watts I think. If the power limit was raised, it would perform better.

    Clamibot, Jul 21, 2020
    #25
  26. Baddemichl

    Baddemichl Notebook Consultant

    Reputations:
    21
    Messages:
    118
    Likes Received:
    136
    Trophy Points:
    56
    The 4940MX will be the bottleneck, because of optimus. To get the full power of RTX5000, you have to go up to 4,6 and higher on all cores.
    If i can remember, the 49xx xm series was not the best cpus to OC.

    Baddemichl, Jul 21, 2020
    #26
  27. Baddemichl

    Baddemichl Notebook Consultant

    Reputations:
    21
    Messages:
    118
    Likes Received:
    136
    Trophy Points:
    56
    Baddemichl, Jul 21, 2020
    #27
    Ashtrix and ssj92 like this.
  28. Maxware79

    Maxware79 Alienware died in 2014

    Reputations:
    218
    Messages:
    1,277
    Likes Received:
    944
    Trophy Points:
    131
    Just a quick side note, there’s a guy on the Dell Community forum who’s running an 18 with a Clevo RTX 2080. I’ve asked him to post over here but he seems reluctant. He said it was pretty much plug and play with no modifications.


    Sent from my iPhone using Tapatalk

    Maxware79, Jul 21, 2020
    #28
  29. ssj92

    ssj92 Neutron Star

    Reputations:
    2,446
    Messages:
    4,446
    Likes Received:
    5,690
    Trophy Points:
    581
    What about in M17xR4 with 120Hz display, there's no Optimus.

    Clevo RTX 2080 is not plug n play, especially since it requires a mod to the MXM socket. @Mr. Fox did this in his P870DM but with 1080 I believe.

    ssj92, Jul 21, 2020
    #29
  30. Maxware79

    Maxware79 Alienware died in 2014

    Reputations:
    218
    Messages:
    1,277
    Likes Received:
    944
    Trophy Points:
    131
    That’s what I said to him but I’m pretty sure he said he didn’t. I’d have to check what he said.


    Sent from my iPhone using Tapatalk

    Maxware79, Jul 21, 2020
    #30
  31. devilhunter

    devilhunter Notebook Evangelist

    Reputations:
    120
    Messages:
    361
    Likes Received:
    254
    Trophy Points:
    76
    sounds crazy, would love to if you can share a link.

    devilhunter, Jul 22, 2020
    #31
  32. @tomX

    @tomX Notebook Evangelist

    Reputations:
    152
    Messages:
    608
    Likes Received:
    77
    Trophy Points:
    41
    @Maxware79 hey, any news from the guy ?

    @tomX, Oct 8, 2020
    #32
  33. @tomX

    @tomX Notebook Evangelist

    Reputations:
    152
    Messages:
    608
    Likes Received:
    77
    Trophy Points:
    41
    Can you please send some benchmarks @razor0601 , to see how it compares to 980m or 1070 thank you .

    @tomX, Oct 8, 2020
    #33
  34. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    Here you go


    Attached Files:

    razor0601, Oct 8, 2020
    #34
    M18x-oldie and electrosoft like this.
  35. M18x-oldie

    M18x-oldie Notebook Evangelist

    Reputations:
    14
    Messages:
    385
    Likes Received:
    129
    Trophy Points:
    56
    Possible for you to also run a regular Firestrike?
    For comparability.

    M18x-oldie, Oct 8, 2020
    #35
  36. @tomX

    @tomX Notebook Evangelist

    Reputations:
    152
    Messages:
    608
    Likes Received:
    77
    Trophy Points:
    41
    And TimeSpy 1.0 please

    @tomX, Oct 9, 2020
    #36
    M18x-oldie likes this.
  37. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    No sorry. I sold the whole Laptop.

    razor0601, Oct 10, 2020
    #37
    Aroc and M18x-oldie like this.
  38. Unfaehig

    Unfaehig Newbie

    Reputations:
    0
    Messages:
    9
    Likes Received:
    0
    Trophy Points:
    5
    How you guys ended up with heatsink modification? Have AMD100W and i'm not sure if worth to try.
    THX!

    Unfaehig, Jul 11, 2021
    #38
  39. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    You can give it a try.

    razor0601, Jul 11, 2021
    #39
    M18x-oldie and Unfaehig like this.
  40. Unfaehig

    Unfaehig Newbie

    Reputations:
    0
    Messages:
    9
    Likes Received:
    0
    Trophy Points:
    5
    The HP card X-Brackets holes looks a bit shifed to right in comperisson to 980M design. So this wasn`t an issue for you?

    Unfaehig, Jul 11, 2021
    #40
  41. razor0601

    razor0601 Notebook Evangelist

    Reputations:
    56
    Messages:
    450
    Likes Received:
    88
    Trophy Points:
    41
    No it wasn‘t.

    razor0601, Jul 11, 2021
    #41
    M18x-oldie likes this.
  42. ssj92

    ssj92 Neutron Star

    Reputations:
    2,446
    Messages:
    4,446
    Likes Received:
    5,690
    Trophy Points:
    581
    For anyone looking into this, here is the ADLINk RTX 3000 version of the card running in the all powerful M18xR2.

    4.1Ghz CPU
    32GB 2133Mhz RAM
    Optimus (SG)

    [​IMG]

    I will be making my own thread with more benchmarks such as TS, FS, PR

    ssj92, Sep 26, 2021
    #42
