    M6000 (7870M) GPU thread

    Discussion in 'Alienware M15x' started by Gofspar, Dec 23, 2015.

  1. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    Alright I got my M6000 today and installed it, people have said its plug and play when its definetly not.

    The GPU die is much lower than the GTX 460M and wont touch the die if you dont use a shim under the backplate or sand the standoffs down.

    Benchies.

    STOCK:
    3DMark Firestrike
    http://www.3dmark.com/3dm/9936134
    http://www.3dmark.com/3dm/9651553 (OVERCLOCKED GTX 460M 800/875)
    Unigine Valley
    [​IMG]

    The M6000 DESTROYS the 460m in Firestrike even when the 460 is overclocked, what a beast.

    Will post overclocked submissions for Valley and 3DMark in a bit.

    Last edited: Dec 26, 2015
    jaybee83 likes this.
  2. King of Interns

    King of Interns Simply a laptop enthusiast

    Reputations:
    1,329
    Messages:
    5,418
    Likes Received:
    1,096
    Trophy Points:
    331
    This is a shame that you need a shim.

    I have never needed a shim with 6970M, 6990M, 7970M and 680M GTX.

    These midrange cards must be put together differently!

    Sent from my SM-A500FU using Tapatalk

  3. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Crap, I was afraid of this. I haven't gotten my card yet, but I do have a spare shim from my MSI GX640 days that I can always use. Gofspar, did you install a shim? If you did, can you tell us the thickness? Each card is made a bit differently. In fact my 240m GT does not make good contact with the heatsink, but I compensate with a bit more thermal paste and it still runs cool. My 640M GTX however makes solid contact with a paper thin layer of paste. Both are official Dell supported M15X cards. I wonder if the problem lies more with the heatsink's copper plate rather than the card itself. May I also ask what x-bracket you used?

  4. fatboyslimerr

    fatboyslimerr Alienware M15x Fanatic

    Reputations:
    241
    Messages:
    1,319
    Likes Received:
    123
    Trophy Points:
    81
    I don't believe you need a shim. Get some custom screws from a hardware shop that are longer than the stock C-clip screws and you won't need a shim!

  5. guda-tucuman

    guda-tucuman Newbie

    Reputations:
    0
    Messages:
    7
    Likes Received:
    0
    Trophy Points:
    5
    Hi all. I wanted to see if it supports an ATI 6870m with my Alienware m15x r2 . excuse my bad English

  6. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Do longer screws allow the heatsink to push further down on to the GPU die? If that's the case, then that's a pretty easy fix.

  7. batfinks

    batfinks Notebook Consultant

    Reputations:
    106
    Messages:
    292
    Likes Received:
    14
    Trophy Points:
    31
    the AMD Firepro M6000 (red pcb) is fully plug and play and no gap between die and heatsink !
    I cannot say about the blue pcb version.

  8. batfinks

    batfinks Notebook Consultant

    Reputations:
    106
    Messages:
    292
    Likes Received:
    14
    Trophy Points:
    31
    I thought about this card many moons ago when upgrading the NVidia 260gtx, and was told by the person selling it that its doesn't work in the alienware m15xr2.
    I never did buy the card, so I cannot say for certain.

  9. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    I've been searching and can't find a single pic of the m6000 with a red pcb.

  10. batfinks

    batfinks Notebook Consultant

    Reputations:
    106
    Messages:
    292
    Likes Received:
    14
    Trophy Points:
    31
    just had a gandrer on ebay and they are all blue pcb versions there also, original dell m6000 pcb was red, the version I got, had.
    I wouldn't mind my friend just picked his laptop up after a all nighter playing battlefront, if I read your post earlier on I could of taken pictures and tests for you

  11. guda-tucuman

    guda-tucuman Newbie

    Reputations:
    0
    Messages:
    7
    Likes Received:
    0
    Trophy Points:
    5
    thank you very much for your answer WANTED SAVER SI was doing something wrong because I WHITE SCREEN AND WINDOWS STARTS BUT NOT SEE NOTHING IN IT

  12. fatboyslimerr

    fatboyslimerr Alienware M15x Fanatic

    Reputations:
    241
    Messages:
    1,319
    Likes Received:
    123
    Trophy Points:
    81
    Yes absolutely able to apply more pressure. Very easy fix :)

  13. King of Interns

    King of Interns Simply a laptop enthusiast

    Reputations:
    1,329
    Messages:
    5,418
    Likes Received:
    1,096
    Trophy Points:
    331
    But we take no responsibility for cracked die ;) be careful when screwing without c-clips. You can easily screw too far

    Sent from my SM-A500FU using Tapatalk

  14. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Crack and it will die :D

  15. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    Yes I have the blue card, I had to use foam infront the backplate to push it away from the card so there was more tension on the card to get a good mount, if someone can find some screws that'll make it do a direct contact without the mod that would be great.

    Wouldn't shorter screws allow it to clamp down farther towards the card?

  16. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    I'll try removing c clips, yolo boys.

    If I kill the little thing I'll just buy M290X.

  17. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    Also mine overclocked to 1Ghz core and 1400 memory ez.

  18. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    alienisme likes this.
  19. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    sanded the backplate down and its fine, card hits 60c overclocked on stock fan curve.

  20. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    sanded down backplate?! details! pictures! benches! screenshots! cant just leave us here hanging like that :D

    Sent from my Nexus 5 using Tapatalk

  21. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    I used Thermal Grizzly and new thermal pads dont wana mess then up, just sand a few mm off of the backplate stand offs.

    doing benches now.

    EDIT: CHECK OP

    Last edited: Dec 26, 2015
    jaybee83 likes this.
  22. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    aaaaah,much better now :) which thermal grizzly paste are u using?

    Sent from my Nexus 5 using Tapatalk

  23. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    Kryonaut, I do extreme overclocking on hwbot.

    It doesn't freeze on dice and LN2 unlike other pastes.

  24. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    good choice, using the same on gpu and clu on cpu :)

  25. guda-tucuman

    guda-tucuman Newbie

    Reputations:
    0
    Messages:
    7
    Likes Received:
    0
    Trophy Points:
    5
    hi , could show such as the installation, pardon my ignorance I am again thanks .

  26. James D

    James D Notebook Prophet

    Reputations:
    2,314
    Messages:
    4,901
    Likes Received:
    1,132
    Trophy Points:
    231
    What's the highest stable OCing you are able to set and what are benches for those? Thanks.

  27. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    975 core, 1400 memory.

    still working some stuff out.

    James D and jaybee83 like this.
  28. guda-tucuman

    guda-tucuman Newbie

    Reputations:
    0
    Messages:
    7
    Likes Received:
    0
    Trophy Points:
    5
    Guide M15x with m6000- 7870m installation, forgive my ignorance.

  29. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Got my card today. It appears brand new like the seller said. I can confirm what Gofspar said about the heatsink not making good contact. It wouldn't spread the paste and only seemed to make contact with the very center of the die. First thing I noticed was the thermal pads I was using were a bit too thick. With my 460m GTX I was using Arctic Cooling 1mm pads for the memory and .5mm pads for the VRMs. Problem with these pads is that they are rather stiff and don't compress very much. For the m6000 I switched to .5mm pads for the memory and 1mm pads for the VRMs. The pads make solid contact and switching to the thinner pads allowed the paste to spread a bit better, but still not good enough. I decided to remove the heatsink screws and c-clamps and replace them. I had some spare screws which are the same length as the originals but are threaded all the way to the screw head unlike the originals. This allows them to be screwed in further and put more pressure on the metal tabs that hold the heatsink to the card's x-bracket. I did not screw the screws in tight to avoid any damage to the die, and now the paste (I'm using MX4) spreads nicely over the entire die.

    I'm in the process of testing it but so far I am getting about 34C at idle, and peaked at 62C after running three benchmarks consecutively (3Dmark06, 3Dmark11, and Furmark Benchmark). Room temp is about 20C. I'm happy so far.

  30. James D

    James D Notebook Prophet

    Reputations:
    2,314
    Messages:
    4,901
    Likes Received:
    1,132
    Trophy Points:
    231
    The thing is that card is HEEEEAVILY downclocked from its desktop colleague so that's why you can OC the hell out of it (temperature-wise) and that's why I am waiting to see the real-world 3Dmark11 benchmark of OCed m6000.

  31. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Well bad news here, all of a sudden I got a white screen and black lines. System would not post and scroll+caps would flash. I removed the heatsink and while the die seems intact, I think I still managed to tighten the heatsink too much, damaging it. I can actually see the imprint of the letters on the die now on my heatsink :eek:. Funny thing is I swore I didn't tighten it too much, but apparently I did. I Tried reseating the card several times and nothing. Back with my 460M GTX now. So let this be a warning to you guys. You can damage the die if too much pressure is applied. I was warned but I still managed to kill my card :p. Oh well, it's not a huge loss at $65 so I'm not gonna worry about it.

    alienisme likes this.
  32. James D

    James D Notebook Prophet

    Reputations:
    2,314
    Messages:
    4,901
    Likes Received:
    1,132
    Trophy Points:
    231
    I feel sorry for you. I guess it was really tight if you could see letters which imprinted through a layer of thermal paste.

    Maybe... it is also due the fact that it was not the equal pressure on the square of the chip. Due to that gap you needed to eliminate, opposite from the heatpipe's direction part of the chip could have bigger pressure so if you do it too hard....

  33. King of Interns

    King of Interns Simply a laptop enthusiast

    Reputations:
    1,329
    Messages:
    5,418
    Likes Received:
    1,096
    Trophy Points:
    331
    Oh dear! What a shame :( the M6000 is at least twice as powerful as the 460M!

  34. Gofspar

    Gofspar Notebook Consultant

    Reputations:
    0
    Messages:
    112
    Likes Received:
    19
    Trophy Points:
    31
    I have mine CLAMPING down on the card like hard and its fine

  35. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    Im thinking on buying the m6000, how it does run gtaV and league of Legends, somebody can tell me?

  36. fatboyslimerr

    fatboyslimerr Alienware M15x Fanatic

    Reputations:
    241
    Messages:
    1,319
    Likes Received:
    123
    Trophy Points:
    81
    For GTA V I would guess you would get 30-40fps on medium settings but with all AA and AO turned off! GTA V can be quite demanding when you start turning on the eye candy. No idea about LOL but doesn't it run well on low-end hardware?

    Borja likes this.
  37. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    LOL shouldnt be a problem with everything maxed out...

    Sent from my Nexus 5 using Tapatalk

    Borja likes this.
  38. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    Thanks you two, i think im gonna save more money and go to 7970m

  39. fatboyslimerr

    fatboyslimerr Alienware M15x Fanatic

    Reputations:
    241
    Messages:
    1,319
    Likes Received:
    123
    Trophy Points:
    81
    I have a broken 7970M that I'm going to try and bake. If it works you can have it. Might only get 6 months out of it though :)

    Borja likes this.
  40. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    good choice as well, since the 7970M is faster than the M6000 ;)

    Borja likes this.
  41. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    If you can send it to Spain we can negotiate something if it works :D

  42. fatboyslimerr

    fatboyslimerr Alienware M15x Fanatic

    Reputations:
    241
    Messages:
    1,319
    Likes Received:
    123
    Trophy Points:
    81
    I am currently in Madrid! :p

    Borja and jaybee83 like this.
  43. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    Borja likes this.
  44. King of Interns

    King of Interns Simply a laptop enthusiast

    Reputations:
    1,329
    Messages:
    5,418
    Likes Received:
    1,096
    Trophy Points:
    331
    Ah good old jaybee our personal M15x fan :) when you getting yours?

    Deadsmiley was like this and ended up buying two M15x's ;)

    It is afterall a special machine

    Sent from my SM-A500FU using Tapatalk

  45. jaybee83

    jaybee83 Biotech-Doc

    Reputations:
    4,125
    Messages:
    11,571
    Likes Received:
    9,151
    Trophy Points:
    931
    lol im not getting one, but i have to admit i caught myself checking out price listings for m15x machines a few months ago :p

    deadsmiley likes this.
  46. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    I bought one yesterday with 240gb ssd, 740qm, 4gb ram and 260m for 460euro ship inc. Im not very patient... I want it to arrive soon xD

    jaybee83 likes this.
  47. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    Welcome aboard amigo :D

    Just installed an i7-920xm on mine. Huge upgrade over the 720qm I had before. Everything is much snappier even at my current stock clocks. Temps are good too, I'm getting around 49C idle and 79C after 10 minutes of prime95. I'm not gonna try overclocking until my 210W PSU come in. I am also waiting on a 7970m that I ordered to replace my 460m.

    Borja likes this.
  48. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    What do you think is better upgrading first (if i dont have too much money and have to do it on parts) cpu or gpu?

  49. kosti

    kosti Notebook Virtuoso

    Reputations:
    596
    Messages:
    2,162
    Likes Received:
    466
    Trophy Points:
    101
    The 740qm is still a fast CPU, even by today's standards. I'd say upgrade it eventually, but I would definitely upgrade the 260m first. I also think you should look into doubling your RAM to 8GB before upgrading the CPU.

    I would look at the AMD 7970m or Nvidia 680m GTX. Just keep an eye on the NBR marketplace or post in the Wanted to Buy forum.

    Borja likes this.
  50. Borja

    Borja Notebook Enthusiast

    Reputations:
    0
    Messages:
    12
    Likes Received:
    1
    Trophy Points:
    6
    Thanks mate! Im gonna wait until i can afford a 7970m, is the most expensive upgrade, 16gb ram are 75 euro moreless, is cheap

 Next page →
