    use laptop without GPU (integrated gpu)

    Discussion in 'Alienware M15x' started by DNOYA, Oct 11, 2018.

  1. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    Hi Bros and Sis,

    can we turn on or use AW without using a dedicated GPU, my friend did flash but uses the wrong VBIOS he suspect the VBIOS that he used is not the MXM VBOS but the Onbord VBIOS AW15, as a result when he turns on the laptop the display screen is only black. but the laptop working. we can hear the sound and enter the windows.

    he already trying to connect with external monitor but is not worked.

    Is there a way to fix or flash the GPU because there is no screen at all?

    Please need a advise whether friends have experienced the same thing

    DNOYA, Oct 11, 2018
    #1
  2. Mastermind5200

    Mastermind5200 Notebook Virtuoso

    Reputations:
    372
    Messages:
    2,152
    Likes Received:
    826
    Trophy Points:
    131
    It depends on the laptop, the M15x has no dedicated GPU

    Mastermind5200, Oct 11, 2018
    #2
  3. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    ----
    in fact the case that happened to my friend was the same as that explained on youtube the following is just the difference this happened on AW15X, on our desktop there are still several options to re-flash again.
    the following link below :



    So from your experience it means that the GPU can't use it at all or in other words there is no way to fix it? :(

    DNOYA, Oct 11, 2018
    #3
  4. Mastermind5200

    Mastermind5200 Notebook Virtuoso

    Reputations:
    372
    Messages:
    2,152
    Likes Received:
    826
    Trophy Points:
    131
    Well you can't boot of the integreated graphics as it doesn't exist in this laptop, you would need a laptop with one

    Mastermind5200, Oct 11, 2018
    #4
  5. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    DNOYA, Oct 11, 2018
    #5
  6. 2CPU

    2CPU Notebook Evangelist

    Reputations:
    22
    Messages:
    363
    Likes Received:
    120
    Trophy Points:
    56
    Just create a blind flash USB with correct VBIOS. Probably need to remove HDD to get USB to select to boot first and have a batch file to execute the flash.

    Like said earlier, PM55 chipset there is no integrated Gpu.

    2CPU, Oct 11, 2018
    #6
  7. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    ---

    I don't think soo because if we put the GPU and trying to turn on, during the POST the screen only black means no sign at all. so we cant select and F2 or F12 key.

    DNOYA, Oct 11, 2018
    #7
  8. xKilXlerx

    xKilXlerx Notebook Geek

    Reputations:
    14
    Messages:
    99
    Likes Received:
    30
    Trophy Points:
    26
    I see on your last post that it is a GTX 980m GPU, maybe you will try to use an old video card for the moment. Or would something like this would work?
    [​IMG]

    Last edited: Oct 11, 2018
    xKilXlerx, Oct 11, 2018
    #8
  9. Mastermind5200

    Mastermind5200 Notebook Virtuoso

    Reputations:
    372
    Messages:
    2,152
    Likes Received:
    826
    Trophy Points:
    131
    Probably

    Mastermind5200, Oct 11, 2018
    #9
  10. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    ------
    i think can be work with this adapter, can you share me the link where to buy it? i think the price should more cheaper than this one


    so if i buy this adapter means i have to put in desktop and reflash right?
    can we install PCIe 1x to slot PCIe 3x (common desktop slot)

    DNOYA, Oct 11, 2018
    #10
  11. DNOYA

    DNOYA Notebook Guru

    Reputations:
    0
    Messages:
    56
    Likes Received:
    8
    Trophy Points:
    16
    ---
    the GPU is GTX 980M

    DNOYA, Oct 12, 2018
    #11
